FUEL Off-Road Throttle, 17x6.5 Wheel with 8 on 6.5 Bolt Pattern – Black Milled – D513176582R

FUEL Off-Road

Shop FUEL Off-Road Wheels 17x6.5 8x6.5 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • FUEL Off-Road Throttle 17×6.5 aluminum wheel in black milled finish
  • Part number D513176582R
  • Bolt pattern 8 on 6.5
  • Offset -140, center bore 125, backspacing -1.84
  • Tagged Universal Fit, with no specific vehicles named

Description

Overview

The FUEL Off-Road Throttle is a 17 x 6.5 inch aluminum wheel in black milled finish, part number D513176582R. The listed bolt pattern is 8 on 6.5, with offset -140, center bore 125 and backspacing -1.84.

This is a narrow 6.5-inch wheel with a large negative offset, so the mounting face sits far outboard of the wheel’s centerline. The -1.84 backspacing means the mounting face also sits outboard of the wheel’s rear edge, which places the wheel further out in the fender.

Key features

  • Throttle style
  • Black milled finish
  • 17-inch diameter and 6.5-inch width
  • Bolt pattern 8 on 6.5
  • Offset -140 and center bore 125
  • Aluminum construction

Mounting clearance checks

A narrow wheel with strongly negative offset changes where the tire sits in the wheel well, so the mounting face position is the first thing to judge. Before fitting it, compare the offset with the wheel you are removing and check how far the tire moves toward the fender and control arms. Most trouble with a wheel like this shows up at full steering lock and under suspension compression, so test both positions with the vehicle safely supported.

Hub-centric rings and wheel spacers are related parts buyers often weigh alongside a wheel like this. A ring centers the wheel on the hub when the center bore is larger than the hub, while a spacer changes the wheel position and the load on studs and wheel bearings. Check the lug nut seat style as well, since a mismatched seat can loosen under load. After rough trail use, inspect the face and lug holes for cracks or bent spokes.

  • Compare hub diameter with the center bore before ordering
  • Check lug seat style against the wheel
  • Recheck lug nut tightness after the first drive

Specifications

Brand FUEL Off-Road
Part number D513176582R
Wheel diameter 17 inches
Wheel width 6.5 inches
Offset -140
Center bore 125
Backspacing -1.84
Style Throttle
Finish Black (specification); Black Milled (title)
Bolt pattern 8 on 6.5
Construction Aluminum
Fitment tag Universal Fit

Vehicle fitment

No vehicle is named, and the Universal Fit tag does not identify one. The 8 on 6.5 pattern is the first check for any vehicle.

A large negative offset changes where the wheel sits in the wheel well, so confirm clearance on your own vehicle. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Offset -140 and backspacing -1.84 place the mounting face well outboard, so check clearance to the fender and suspension before any driving. If your hub measures less than 125, a hub-centric ring may be needed to center the wheel.

What’s included

This is one wheel. Tires and lug nuts are not included.

Not included: Tires and lug nuts.

SKU: MHTD513176582R Categories: ,

Questions & Answers

What are the size and offset of the FUEL Off-Road Throttle 17x6.5?

It is 17 inches in diameter and 6.5 inches wide, with offset -140, center bore 125 and backspacing -1.84. The part number is D513176582R and the bolt pattern is 8 on 6.5.

Does this wheel fit a truck with 8 on 6.5 bolts?

The 8 on 6.5 bolt pattern is the first match to check, but no vehicle is confirmed, so fit is unknown. Check hub bore, offset and clearance on your own vehicle before using it, and confirm fit for its year, model and trim before ordering.

Is the finish black or black milled?

Black and black milled refer to the same finish on this wheel. The face is black milled aluminum, so both terms describe one finish.

How do I know if a hub-centric ring is needed?

Compare the hub diameter with the wheel's center bore. If the hub is smaller than the bore, a hub-centric ring is usually needed to center the wheel and reduce vibration.
