Firestone Ride-Rite Sport-Rite Air Helper Spring – 9001

Firestone Ride-Rite

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Firestone Ride-Rite Sport-Rite air helper spring, part number 9001
  • Medium duty construction with up to 3000 lbs of leveling capacity
  • Tapered spring design
  • Direct Fit part; confirm fit for your vehicle before ordering

Description

Overview

The Firestone Ride-Rite Sport-Rite Air Helper Spring, part number 9001, is a medium duty air helper spring for leveling a vehicle under load. It carries the Firestone Ride-Rite brand and is marked as a Direct Fit part.

The tapered spring design provides up to 3000 lbs of leveling capacity. It helps keep the vehicle level, levels off-center loads, reduces suspension fatigue and bottoming out, and improves stability, with air pressure adjustments to fine-tune the ride.

Key features

  • Medium duty Sport-Rite air helper spring
  • Tapered spring design
  • Up to 3000 lbs of leveling capacity
  • Helps level off-center loads
  • Reduces suspension fatigue and bottoming out
  • Air adjustments improve the ride and vehicle stability

Signs a helper spring needs service

Air helper springs share the load with the factory springs, so their condition affects how the rear end sits and rides. Over time the rubber bellows and fittings can crack, leak or lose air, and a spring that is losing pressure may let the vehicle sag when loaded. Check the bellows for cuts, look for bulges, and listen for hissing near the fittings.

Helper springs are often inspected together with the shocks, bump stops and mounting hardware, since worn parts there can shift load onto the spring. Keep the air lines clear of the frame and tires. Periodic checks with the vehicle loaded and unloaded show whether the spring still holds its height, and a spring used with other suspension upgrades may need a check after those parts change.

  • Cracks or abrasion on the bellows
  • Air loss when the system is at rest
  • Uneven ride height from side to side

Specifications

Brand Firestone Ride-Rite
Part number 9001
UPC 4223801
Product type Sport-Rite medium duty air helper spring
Leveling capacity Up to 3000 lbs
Spring design Tapered
Fitment listing Direct Fit

Vehicle fitment

Part 9001 is a Direct Fit part. Confirm fit for your vehicle’s year, model and trim before ordering.

Confirm your vehicle’s year, model and trim before ordering.

What’s included

The Sport-Rite medium duty air helper spring is the item included with part 9001.

SKU: FIR9001 Category:

Specification

Shipping weight 2.67 lbs
Package dimensions 9.00 × 7.50 × 5.50 in
brands

Questions & Answers

What is Firestone Ride-Rite part number 9001?

Part 9001 is a Firestone Ride-Rite Sport-Rite air helper spring, a medium duty unit that provides up to 3000 lbs of leveling capacity. It uses a tapered spring design to help keep a vehicle level under load.

Does part 9001 provide 3000 lbs of leveling capacity?

Yes, it provides up to 3000 lbs of leveling capacity. That figure is an upper limit, so the actual leveling load depends on the vehicle and the air pressure used.

Will part 9001 fit my vehicle?

It is a Direct Fit part. Match your vehicle's year, model and trim to the part before you buy, and confirm the fit first.

What is the UPC for Firestone Ride-Rite part 9001?

The UPC for Firestone Ride-Rite part number 9001 is 4223801. Use the part number and UPC together when matching this Sport-Rite medium duty air helper spring to your order.

How can I tell if an air helper spring is worn?

Look for cracks or abrasion on the bellows, air loss when the system is at rest, and uneven ride height from side to side. A spring that loses air quickly or sags under load usually needs inspection or replacement before the rest of the suspension is affected.

Should air helper springs be inspected with other suspension parts?

Yes. Shocks, bump stops and mounting hardware carry load alongside the helper spring, so wear in those parts can shift stress onto it. Inspecting them together gives a clearer picture of how the suspension is holding up.
