Overview
The Firestone Ride-Rite Front Air Helper Spring Kit (part 2223) adds air helper support to the front of a vehicle. It uses a leaf spring mount and is rated at 3,200 lbs per pair, which suits leveling the front end when a load is heavy.
The kit uses double convoluted air springs that inflate by hand. Drilling is required, and lift kit compatibility is yes, though spacers may be needed. It helps level off-center loads, reduces bottoming out and improves stability. Confirm the front suspension type on your vehicle before ordering.
Key features
- Front application for leveling the front end
- Leaf spring mount design
- Double convoluted air springs
- Load capacity of 3,200 lbs per pair
- Manual inflation with an optional height sensor
- Helps reduce bottoming out and increase stability
Front air helpers on leaf springs
A front air helper spring adds support to the front suspension, which can help when the nose sits low or when the front end is loaded. Leaf spring mounts are a different setup from coil or torsion systems, so the mounting method and clearances need to be checked before fitting the air springs.
Front air springs affect steering and braking feel only through the load they add, so check that the steering components, tires and brakes are in good shape. Clearance should be checked at full steering lock and over rough ground. If the vehicle has a lift, spacers may change the geometry, so recheck alignment after installation.
- Check clearance at full steering lock
- Look for rubbing against the frame or brackets
- Recheck alignment after any lift or spacer change
Specifications
| Brand | Firestone Ride-Rite |
|---|---|
| Part number | 2223 |
| UPC | 767555098745 |
| Application | Front |
| System type | Leaf spring mount |
| Load capacity | 3,200 lbs per pair |
| Leveling capacity (description) | Up to 5000 lbs |
| Bag/spring type | Double convoluted |
| Installation type | Requires drilling |
| Inflation method | Manual inflation |
| Height sensor | Optional |
| Lift kit compatible | Yes, may require spacers |
Vehicle fitment
Firestone names no vehicles and shows a direct fit front air bag application. Because this is a leaf spring mount kit, confirm the front suspension type on your vehicle first.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Drilling is required, and spacers may be needed with a lift kit. Check front clearance after mounting the air springs.
What’s included
A compressor, gauges and height sensor are optional add-ons. Plan for inflation equipment and a height sensor separately if you want them.
