Overview
The Fab Fours TF2900-1 is an open fender base system for the 2016–2018 Ram 2500 and Ram 3500, supplied as a set of four in powder coat under part number FFITF2900-1. It is built to run a 40-inch tire with no lift, which keeps the center of gravity low while giving an aggressive stance.
The base system is modular, so the optional fender flares (TF4110-1) can be run with it or left off. The system keeps a truck’s working utility while adding a styled look, and it covers front and rear locations.
Key features
- Open fender design for a 40-inch tire with no lift
- Modular system that runs with or without optional flares
- Set of four covering the front and rear locations
- Keeps the utility of a work truck
- Powder coat finish
Tire size, stance and steering
Running a 40-inch tire with no lift changes the way a truck handles and where clearance matters most. Taller tires add rotating weight and can change gearing feel, so expect slower throttle response and a slightly different ride. The biggest concern is steering and driveline clearance at full lock, where a tire can rub the open fender edge.
Open fender bases leave the wheel area more exposed to mud, rock spray and water. Clean the inner wheel area after wet or muddy trips, and check brake lines, wiring and sensor harnesses for rubbing. Tire pressure and alignment also matter more on taller tires, so check them after changing tire size. Re-torque the wheel lugs after the first short drive.
- Check full-lock clearance before the first trip
- Inspect wiring and brake lines after rough trails
- Recheck wheel torque after the first short drive
Specifications
| Brand | Fab Fours |
|---|---|
| Part number | FFITF2900-1 |
| Quantity | Set of 4 |
| Location | Front and rear |
| Width and coverage | Stock width and coverage |
| Finish | Powder coat |
| Tire size supported | 40-inch tire |
| Fit type | Direct fit |
Vehicle fitment
It fits the 2016–2018 Ram 2500 in the Big Horn, Laramie, Laramie Longhorn, Limited, Outdoorsman, Power Wagon, SLT and Tradesman trims. It also fits the 2016–2018 Ram 3500 in the Big Horn, Laramie, Laramie Longhorn, Limited, Lone Star, SLT and Tradesman trims.
Ram 1500 models and other Ram years are not on this list. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The system is built to run a 40-inch tire with no lift, so check steering and driveline clearance at full lock with the tire you plan to run. Mounting hardware is not part of the kit, so plan the installation steps before starting.
What’s included
The set contains four pieces covering the front and rear, and no hardware is named.
Not included: The optional fender flares TF4110-1 are a separate purchase and are not in the set.
