Overview
The Baja Designs Squadron-R Sport Fog Pocket Kit, part number 447066, is a replacement fog light kit for the 2018-2022 Jeep Wrangler JL Sport and Sport S, 2 and 4 door, with the plastic Sport/Sport-S bumper. It replaces the factory fog pocket lights with a pair of Squadron-R Sport LED lights while keeping the factory fit and finish.
Each light has four LEDs producing 2,260 lumens at 20W and 1.4A. The housing is hard anodized and powder coated cast aluminum, measuring 3.07 x 2.77 x 3.07 in. The LED life expectancy is 49,930 hours, and the kit suits drivers who want aftermarket LED output at the front of a JL Sport.
Key features
- Pair of Squadron-R Sport LED lights for the fog pockets
- 2,260 lumens per light from four LEDs
- Brackets that use the stock mounting points
- Wire adapters that plug into the OEM connectors
- Hard anodized, powder coated cast aluminum housing
- LED life expectancy of 49,930 hours
Keeping the front end working
Fog pocket lights sit low in the bumper where water, mud and road salt collect. Once the lights are in, a periodic check keeps them working well. Look at the lenses for film or cracks, wipe the housings with mild soap, and make sure the plug-in connectors are seated fully. Corroded or loose connectors are a common cause of flicker in aftermarket lights.
Because the wire adapters use the factory connectors, the factory fog switch and its wiring stay in service. If the lights dim or stop, check the fuse and the connector before assuming the lamp has failed. Re-tighten the brackets after a few weeks of driving on rough roads, since vibration can loosen hardware over time.
- Check lenses for film, grit or cracks
- Wipe housings with mild soap and water
- Inspect plug-in connectors for corrosion
- Re-tighten brackets after the first few weeks
Specifications
| Brand | Baja Designs |
|---|---|
| Part number | 447066 |
| UPC | 819314026954 |
| Light model | Squadron-R Sport |
| LEDs per light | 4 |
| Lumens | 2,260 per light |
| Wattage / amps | 20W / 1.4A |
| Dimensions | 3.07″ x 2.77″ x 3.07″ |
| Housing | Hard anodized and powder coated cast aluminum |
| LED life expectancy | 49,930 hours |
| Fitment | 2018-2022 Jeep Wrangler JL, Sport and Sport S |
Vehicle fitment
The kit fits 2018-2022 Jeep Wrangler JL models, 2 and 4 door, in Sport and Sport S trims with the plastic Sport/Sport-S bumper. The range follows the JL generation, which starts with the 2018 model year.
This kit is not for the metal Rubicon bumper or the plastic Sahara bumper, and it does not cover earlier Wrangler generations such as the JK. A Rubicon with a plastic bumper uses the Sahara kit, part number 447071. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The wire adapters plug into the OEM connectors, so the factory fog switch stays in use with no splicing or soldering. Confirm the vehicle has the plastic Sport or Sport-S bumper before starting, since the brackets fit that bumper. Route and fuse any added wiring to standard practice.
What’s included
A pair of Squadron-R Sport LED lights, two sets of Jeep JL mounting brackets, plug and play wiring connectors, and mounting hardware.
