Overview
The Baja Designs SAE Fog Light Pocket Kit (Amber), part number 447715, is a street legal SAE certified fog light based on the Squadron series. It is designed for the 2015-2019 Chevrolet Colorado and GMC Canyon.
Its pattern and circuitry are tuned for street legal output, and it is designed as an upgrade over most LED, HID and halogen factory fog lights. The kit runs 22 watts and carries an IP69K rating.
Key features
- SAE certified fog light based on the Squadron series
- Built-in overvoltage protection
- IP69K waterproof, submersible to 9 feet
- IK10 impact rating and MIL-STD810G testing
- Billet machined aluminum bezel
- Hard anodized, powder coated cast aluminum housing
Street legal fog lighting basics
Street legal fog lights are built to a set of compliance rules, so the light’s pattern, color and output are measured against a standard. Local rules still apply, and some areas restrict how fog lights may be used with high beams or on certain roads. Check your state’s rules before the lights go on a public road.
On a pickup, the fog pocket is a good spot for a low, protected light, but the bezel and lens take the brunt of gravel and brush. Check the bezel for chips after trail use, and keep the lens clear of mud so the beam stays even. Stainless hardware resists corrosion, but a little grease on any bolt that is removed often makes it easier to service.
Aluminum housings conduct heat away from the LEDs, so keep the vents and the back of the housing clear of foam and mud. A dim or flickering light usually points to a loose connector, a corroded ground or a relay problem rather than a failed LED.
Specifications
| Brand | Baja Designs |
|---|---|
| Part number | 447715 |
| Watts | 22 |
| Amps | 1.6 |
| LED life | 49930 hours |
| Front lens | Hard coated polycarbonate |
| Bezel | Billet machined aluminum |
| Housing | Hard anodized and powder coated cast aluminum |
| Hardware and bracket | Stainless steel |
| Waterproof | IP69K, submersible to 9 feet |
| Impact | IK10 compliant |
| Testing | Exceeds MIL-STD810G |
| Color | Amber |
Vehicle fitment
It fits the 2015-2019 Chevrolet Colorado in Base, LT, WT, Z71 and ZR2 trims, and the 2015-2019 GMC Canyon in All Terrain, Base, Denali, SL, SLE and SLT trims.
For other Colorado or Canyon model years, or 2020 and later trucks, check the fit against your vehicle before ordering.
Installation notes
The kit mounts directly on the trucks above, with stainless steel hardware and brackets. Check the fog pocket fit and the wiring harness before installing. The lens is hard coated polycarbonate, and the light is IK10 rated for mechanical impact and tested to MIL-STD810G. Check the bezel and lens after mounting, and confirm the fog pocket clears the bezel.
What’s included
The SAE fog light with its bezel, bracket and stainless steel hardware.
