Overview
The Rugged Ridge 18760.29 is a 40 tooth short shaft speedometer gear for electrically driven speedometers. It is a direct OE replacement for 93-01 Jeep Cherokee, 93-98 Grand Cherokee and 93-06 Wrangler applications.
It is a bolt-on installation. Confirm the speedometer is electric before ordering.
Key features
- 40 tooth count on a short shaft
- Direct OE replacement speedometer gear
- Bolt-on installation described by the brand
- Electrically driven speedometer applications
Speedometer gear basics
The speedometer gear turns with the drivetrain and sends a signal that the speedometer uses to show speed. Because the reading depends on tooth count, a worn or mismatched gear can make the speedometer read high or low, or stop reading at all. Gear wear often shows up as an erratic needle or a dead gauge at normal road speed.
When replacing the gear, look at the speedometer housing, the seal, and the wiring or sensor connected to it. Old grease or debris in the housing can cause a new gear to wear quickly. Clean the area before installing, and check that the gear turns freely once in place.
- Compare the new gear’s tooth count with the old one before installing
- Inspect the housing seal for leaks or damage
- Remove debris from the housing before reassembly
- Test the speedometer on a short drive after installation
Specifications
| Brand | Rugged Ridge |
|---|---|
| Part number | 18760.29 |
| UPC | 804314254711 |
| Tooth count | 40 teeth |
| Shaft length | Short shaft |
| Speedometer type | Electric |
Vehicle fitment
Rugged Ridge lists 93-01 Jeep Cherokee, 93-98 Grand Cherokee and 93-06 Wrangler for electrically driven speedometers. The product’s Universal Fit label is secondary to those year and speedometer limits.
Confirm the speedometer is electric and that your year, model and trim match before ordering.
Installation notes
Check that the new gear sits in the same speedometer setup as the one you remove.
What’s included
The package is the speedometer gear, part 18760.29, with no other parts included.
