Overview
The Warn Series 15 hydraulic industrial winch, part number 65931, has a maximum rated load of 15000 lbs. (6818 kgs). It is designed for medium duty wreckers, carriers and trailers.
The winch is powered by a 5.9 cubic inch hydraulic motor, which provides pulling capacity up to 15,000 lbs. It uses a hardened steel, two-stage planetary gear train with a 36:1 reduction, and it is built to meet SAE J706 and CE standards.
Key features
- Pulling capacity up to 15,000 lbs. from a 5.9 cubic inch motor
- Hardened steel, two-stage planetary gear train with 36:1 reduction
- Heavy-duty automatic disc brake
- Positive locking clutch that keeps the winch from jumping out of gear
- Meets SAE J706 and CE standards
- Maximum input flow of 16 USGPM (60 L/MIN)
- Anti-clockwise rotation for part 65931
Hydraulic power and flow
The hydraulic power unit controls how this winch performs. Pump output, hose diameter and fitting size all affect how smoothly the drum turns under load. Oversized hoses reduce pressure drop, while undersized hoses restrict flow and can heat the fluid. Use a filter in the circuit and keep fluid clean to protect the gear train.
Medium duty recovery jobs often involve repeated pulls, so monitor fluid temperature and the sound of the gears. A hot reservoir or a sudden change in noise can signal a restriction or wear. Check the valves and hose ends for leaks each time the equipment is serviced.
- Use a filter in the hydraulic circuit
- Keep hydraulic fluid clean and at the right level
- Watch fluid temperature during repeated pulls
Specifications
| Brand | Warn |
|---|---|
| Part number | 65931 |
| UPC | 12748659310 |
| Series | Series 15 hydraulic industrial |
| Winch type | Hydraulic |
| Maximum rated load | 15000 lbs. (6818 kgs) |
| Maximum wire rope recommended | 1/2 |
| Minimum breaking strength of recommended rope | 26600lbs (12091kg) |
| Maximum input flow | 16 USGPM (60 L/MIN) |
| Hydraulic motor | 5.9 cu in (96.7 cc) |
| Gear ratio | 36:1 |
| Drum barrel diameter | 4.0 (102mm) |
| Drum flange diameter | 8.24 (209mm) |
| Distance between flanges | 9.95 (253mm) |
| Standards | SAE J706, CE Machinery Directive 98/37/EEC |
| Remote control | None |
| Fairlead | None |
| Line type | Wire |
Vehicle fitment
The winch is designed for medium duty wreckers, carriers and trailers. Confirm fit for your equipment’s year, model and trim before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The hydraulic power source must deliver the maximum input flow of 16 USGPM (60 L/MIN). Confirm pump and hose sizing for your system, and mount the winch to a frame rated for the 15000 lbs. maximum load. Keep people clear of the wire rope under load.
What’s included
Check the package contents against your installation before starting, including the controls, hardware and rope.
Not included: Wire rope, the hydraulic power source and hoses are not part of the package. The recommended rope is 1/2 with a minimum breaking strength of 26600lbs (12091kg).
