Overview
The Warn 67970 is a drive shaft listed at 12.023 in. x .312 in., a replacement part for Warn winches under part number 67970. Owners use a drive shaft like this one when repairing a winch, so the correct match depends on the winch itself. No vehicle is named for it; fitment is tied to the winch.
Key features
- Replacement drive shaft measuring 12.023 in. x .312 in.
- Warn part number 67970 and UPC 12748679707
- Built for Warn winch repair, not a vehicle-specific installation
- Winch model, battery voltage and serial number needed before ordering
Drive shaft wear and replacement
A winch drive shaft transfers rotation from the motor to the gear train, so it works under constant torque and shock loads. Over time the shaft ends can round off, splines can wear, and bearing surfaces can score. Those signs often show up as slipping, grinding or a noticeable drop in pulling ability under load.
When a drive shaft is replaced, the gears and bearings that mate with it are commonly inspected at the same time. Worn splines on a gear can damage a new shaft quickly. Clean the shaft and mounting surfaces, and check that the shaft turns freely by hand before reassembly.
- Check spline ends for rounding
- Inspect bearing surfaces for scoring
- Test for smooth rotation before reassembly
Specifications
| Brand | Warn |
|---|---|
| Part number | 67970 |
| UPC | 12748679707 |
| Part type | Drive shaft, winch replacement part |
| Size | 12.023 in. x .312 in. |
Vehicle fitment
No vehicle list is attached to this drive shaft. It is matched to the winch, so check the winch model before anything else. Warn’s product information marks it universal fit, which means it is not sized for a particular truck or Jeep.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Gather the winch model number, battery voltage and serial number first. On planetary gear winches the serial number sits on the gear end housing; on upright spur gear models (M8274) it is on the top of the winch housing.
What’s included
The drive shaft is the only item covered here. Confirm the hardware your installation needs before starting.
