Overview
The TeraFlex HD drag link flip kit with front track bar drop bracket and frame brace kit 1600450 (TER1600450) is a steering kit for the 2007-2018 Jeep Wrangler JK and JKU with Dana 30 or Dana 44 front axles and 4-6 inch lift kits.
The kit keeps steering geometry in line for highway driving. The heavy-duty drag link, which is 50% stronger than the factory part, is flipped over the knuckle to help reduce front-end shimmy. The track bar drop bracket corrects steering geometry, and the frame brace reinforces the frame to reduce movement.
The drag link threads into the factory adjusting sleeve, so the stock adjustment method is kept, while the track bar bracket and frame brace address related front-end problems together.
All parts are supplied as one kit.
Key features
- Heavy-duty drag link, 50% stronger than the factory part
- Flips the drag link over the knuckle
- Front track bar drop bracket
- Frame brace kit
- Threads into the factory adjusting sleeve
- Compatible with factory and aftermarket axle shafts, ball joints, hubs and tie rods
- Does not affect ESP, ABS or traction control
Steering setup and alignment
Front steering geometry is a set of linked angles, so a change to one link usually shifts the others. A drag link, track bar and frame brace work together to keep the front wheels tracking straight as the suspension moves. After a lift, the stock geometry is often off, which can show up as wander, shimmy or tire wear on the front tires.
Check the steering after installation. Start with the drag link and track bar ends, then look at the frame brace mounts for fresh cracks or movement under load. Alignment should be checked once the parts are in, and recheck the steering stop and the bolts after the first few drives. Keep the steering stabilizer and tie rod ends in good condition, since they carry the same loads.
- Check drag link and track bar ends for play
- Inspect frame brace mounts for cracks
- Schedule an alignment after the lift and parts are in
- Retorque steering bolts after the first drives
Specifications
| Brand | TeraFlex |
|---|---|
| Part number | TER1600450 |
| Axles | Dana 30 and Dana 44 |
| Lift range | 4-6 inches |
| Drag link | Heavy-duty, tapered insert mount at knuckle |
| Fit type | Direct fit |
Vehicle fitment
It fits the 2007-2018 Jeep Wrangler (JK), in two-door and Unlimited four-door versions.
The JL and TJ are not covered. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The new drag link threads into the factory adjusting sleeve and uses a tapered insert to mount to the knuckle. Fit is intended for JKs with 4-6 inch lift kits.
What’s included
A heavy-duty drag link flip kit, a front track bar drop bracket and a frame brace kit.
