Rubicon Express Mono-Tube Shock Absorber – RXJ603B

Rubicon Express

Shop Jeep Cherokee XJ Shock Absorbers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front extreme duty mono-tube shock, gas charged, sold as each
  • Rated for a 5.5 inch lift
  • Fits 1984–2001 Jeep Cherokee XJ and 1997–2006 Wrangler TJ
  • Part number RXJ603B

Description

Overview

The Rubicon Express Mono-Tube shock absorber, part number RXJ603B, is a front extreme duty mono-tube shock for the 1984–2001 Jeep Cherokee XJ and the 1997–2006 Jeep Wrangler TJ. It is gas charged and rated for a 5.5 inch lift.

Rubicon Express develops and tunes its Extreme-Duty mono-tube shocks for each application, aiming for control over the toughest terrain while keeping ride quality, high-speed stability and comfort on longer trips. The specifications give an extended length of 30.2 and a collapsed length of 18.4.

Key features

  • Extreme-Duty mono-tube design
  • Gas charged
  • Front position
  • Rated for a 5.5 inch lift
  • Sold as each

Front shock wear and handling

Front shocks handle a large share of steering and braking motion, and on a solid-axle Jeep they also control the way the axle moves over uneven ground. When a front shock loses damping, the vehicle may wander on the highway or feel loose when the brakes are applied. Checking the shocks at each brake or tire service is an easy way to catch wear before it affects control.

A front shock should be replaced with its matching position and length, and the mounts should be checked for wear at the same time. If one front shock is replaced, replacing the opposite side keeps the two sides balanced. Tire wear that shows cupping or uneven patterns can also point to a worn front damper.

  • Check for fluid leaks along the shock body
  • Look for cupped or uneven tire wear
  • Replace front shocks in pairs for balanced steering
  • Inspect eye mounts and bushings for play

Specifications

Brand Rubicon Express
Part number RXJ603B
UPC 614901451740
Shock series Extreme-Duty Mono-Tube
Position Front
Extended length 30.2
Collapsed length 18.4
Lift rating 5.5 in lift
Gas charge Gas charged
Fitment Direct fit
Quantity Sold as each

Vehicle fitment

It is a direct fit for the 1984–2001 Jeep Cherokee (XJ) and the 1997–2006 Jeep Wrangler (TJ). Wrangler JK and JL models are outside that fit. Confirm your vehicle’s year, model and trim before ordering.

The list covers the XJ and TJ only, so Wrangler JK and JL models are not included. Confirm your vehicle’s year, model and trim before ordering.

What’s included

One front shock, sold as each.

SKU: R/ERXJ603B Category:

Specification

Shipping weight 6.00 lbs
Package dimensions 36.00 × 4.00 × 4.00 in
brands

Fitment

VehicleYearsTrims
Jeep Cherokee (XJ)1984–2001Base, Briarwood, Chief, Classic, Country, Laredo, Limited, Pioneer, SE, Sport
Jeep Wrangler (TJ)1997–200665th Anniversary Edition, Rubicon, SE, Sahara, Sport, X

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the RXJ603B fit a 1999 Jeep Cherokee XJ?

Yes. The list includes the 1984–2001 Jeep Cherokee XJ, so 1999 falls within the covered years. Confirm your vehicle's year, model and trim before ordering.

Is it a front or rear shock?

It is a front shock. It is built for the front position and fits the listed Jeep models, not a rear application.

Does it fit a 5.5 inch lift?

Rubicon Express rates the shock for a 5.5 inch lift, so it is set up for that height. Confirm that the lift on your vehicle matches before installing.

What is the extended length?

The specifications give 30.2 as the extended length and 18.4 as the collapsed length. Measure your mounts to confirm the fit before ordering.

Should front shocks be replaced in pairs?

Yes, in most cases. Replacing both front shocks keeps damping the same on each side, which helps steering feel even and keeps the vehicle tracking straight. Confirm the position and fit for your vehicle before ordering each unit.

What signs point to a failing front shock?

Look for oil on the shock body, excessive bounce after a bump, nose dive under braking, or uneven tire wear. A knocking sound over rough ground can also point to worn mounts or bushings that should be checked with the shock.
