Overview
The Rigid Industries SR-Series Pro 30 Inch Light Bar in a driving/spot combo, part number 931314, is a single row LED light bar. Rigid rates it at 205 watts, with 34 LEDs, a 14.64 amp draw and 21318 raw lumens. It is a universal light bar with no vehicle named for it.
The SR-Series PRO is a low profile bar that measures less than 2 inches tall. It uses a patented Specter optic and reaches a beam distance of 617 m. It comes in a black or white powder coated finish, and this version is black with a clear lens.
A driving/spot combo mixes a wide driving pattern with a narrow spot, so the bar lights the road ahead and reaches far down it. Instant on and off means it reaches full output immediately, with no warm-up period. The SR-Series PRO comes in a wide range of lengths and configurations for vehicles, industrial, agricultural and marine uses.
Key features
- Driving/spot combo beam
- Single row of LEDs, under 2 inches tall
- Patented Specter optics
- Instant on and off with no warm up
- Durable polycarbonate lens
- Designed, engineered and assembled in the USA, per Rigid
Choosing a driving beam
Beam pattern matters more than raw output for most drivers. A spot pattern concentrates light down the trail, which helps on open desert runs and fast highway use. A flood pattern spreads light to the sides, useful in tight brush. A combo sits between the two, so one bar can cover several conditions. Compare the terrain you drive most before deciding.
A low profile bar sits close to the body or a roof rack, so leave room for airflow and keep the lens clear of mud and branches. Dirt on the surface cuts output more than many owners expect, so wipe it down after each outing.
- Inspect the bracket for corrosion before each season
- Recheck mounting bolts after the first few trail runs
- Look for chafing on the harness near panel edges
Specifications
| Brand | Rigid Industries |
|---|---|
| Part number | 931314 |
| UPC | 849774031458 |
| Series | SR-Series Pro 30 inch light bar |
| Size | 30 inch |
| Beam pattern | Driving/spot combo |
| Watts | 205 |
| Amp draw | 14.64 |
| LEDs | 34 |
| Raw lumens | 21318 |
| Beam distance | 617 m |
| Lifespan | 50,000+ hours |
| Lens | Clear, durable polycarbonate |
| Finish | Black |
Vehicle fitment
No vehicle, year or model is named for this universal bar. Choose a flat mounting spot with room for a 30 inch bar and confirm the mount before ordering.
Confirm your vehicle’s year, model and trim before ordering any bracket.
Installation notes
At 14.64 amps, the bar should be run through a fused circuit with a relay and a switch. Local rules for light bars on public roads should be checked before the bar is fitted and used.
What’s included
One 30 inch SR-Series Pro driving/spot combo light bar in black.
