Overview
The Rigid Industries Radiance Red Back-Light Pod, part number 20202, is a 3 inch square black pod with a red back-light that runs separately from the main light. It is a universal pod built with the same high-grade aluminum alloy housing as the D-Series lights.
The pod uses forward projecting optics for the main light and a red back-light. It is rated at 15 watts, 900 raw lumens and an amp draw of 1, with three LEDs. It carries IP68 compliance, an alloy housing and heatsink, and a high impact polycarbonate lens, and it is sold as a pair with brackets and a wiring harness.
Key features
- Red back-light, independently controlled
- Forward projecting optics
- Black exposed printed circuit board
- Alloy housing and heatsink
- IP68 compliant, high impact polycarbonate lens
- Brackets and wiring harness included
Mounting and wiring tips
Surface mounted pods work best on flat, solid panels where the bracket can seat fully and the bolts can be tightened evenly. Check that the wiring entry is sealed with a grommet or sealant, and let the harness form a drip loop below the connection so water runs away from the plug. Aim the forward optic before final tightening, and keep the red back-light angle in mind when setting the pod position.
Because the back-light is controlled separately, plan the switch setup before wiring. A dedicated switch lets you run the red light alone, or with the main light off. Keep the supply within the pod’s voltage range and use a fused circuit. Clean the lens with mild soap and water, and check the seal after heavy washing or mud exposure.
Specifications
| Brand | Rigid Industries |
|---|---|
| Part number | 20202 |
| UPC | 815711012644 |
| Series | Radiance Pod |
| Back-light | Red, independently controlled |
| Housing | 3 inch square, black |
| Mounting | Surface, brackets included |
| Voltage | 9-15 V DC |
| Watts | 15 |
| Amp draw | 1 |
| LEDs | 3 |
| Raw lumens | 900 |
| Waterproof rating | IP68 |
| Beam | Fog |
Vehicle fitment
This universal pod has no year, make or model listed. The surface mount and brackets decide where it can go, so pick a flat spot that suits a 3 inch square housing.
Confirm your vehicle’s year, model and trim before ordering any bracket.
Installation notes
The pod runs on 9 to 15 volts DC and should be wired to a fused DC supply in that range. Red lighting is restricted in some areas, so check local rules before using the back-light on public roads.
What’s included
Two Radiance Red back-light pods, with mounting brackets and a wiring harness.
