Rancho RS5000 Series Shock Absorber – RS5396

Rancho

Shop Nissan Armada Shock Absorbers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Rancho RS5396 rear shock for the 2005–2008 Nissan Armada LE, SE and SE Off-Road
  • Gas charged hydraulic design with ten-stage velocity sensitive valving
  • 5/8-in. (16mm) piston rod and 1 3/8-in. (35mm) piston
  • Red protective boot included, sold as each

Description

Overview

The Rancho RS5396 is a rear shock absorber from the RS5000 Series, made for the 2005–2008 Nissan Armada in LE, SE and SE Off-Road trim. It is a gas charged hydraulic shock intended for sport utility vehicles driven on paved and unpaved roads.

The RS5000 line is a workhorse shock for light trucks and SUVs. The RS5396 uses ten-stage velocity sensitive valving, which changes damping force with shock speed, along with a piston rod of 5/8-in. (16mm) diameter and a piston of 1 3/8-in. (35mm) diameter.

Sold as each, the RS5396 replaces one rear shock at a time. Vehicles with two rear shocks need two units to keep both sides matched, and each unit comes with a red protective boot.

Key features

  • Rear position, gas charged hydraulic shock
  • Ten-stage velocity sensitive valving
  • 5/8-in. (16mm) diameter piston rod
  • 1 3/8-in. (35mm) diameter piston
  • Red protective boot included
  • Designed for stock-height use, with a lift height of 0 in.
  • Rancho limited lifetime warranty

Care after installation

After a new rear shock is installed, a short check helps the unit settle in. Recheck the mounting bolts after the first few drives, since fasteners can loosen as bushings seat. Look at the shock body for fluid residue and listen for knocking over bumps, which can point to a mounting issue rather than the shock itself.

Armada owners who use the vehicle for towing, off-road trips or heavy cargo should inspect rear shocks more often than those who drive mostly on pavement. Keep the dust boot in place, since it guards the piston rod from grit. Clean the rod after muddy use and avoid spraying water directly at the seals. Replacing the shock in pairs keeps damping consistent from side to side.

  • Recheck mounting bolts after the first drives
  • Inspect the dust boot for tears
  • Clean the piston rod after muddy trips

Specifications

Brand Rancho
Part number RS5396
UPC 10039703002995
Series RS5000 Series
Position Rear
Fitment type Direct fit
Shock type Hydraulic, gas charged
Valving Ten-stage velocity sensitive
Piston rod diameter 5/8-in. (16mm)
Piston diameter 1 3/8-in. (35mm)
Lift height 0 in. lift/drop
Included Red protective boot
Sold as Each

Vehicle fitment

It fits the 2005–2008 Nissan Armada in LE, SE and SE Off-Road trim. Confirm fit for your vehicle’s year, model and trim before ordering.

Nissan Pathfinder, Xterra and Titan applications are not covered by this fitment. Confirm your vehicle’s year, model and trim before ordering.

What’s included

One Rancho RS5396 rear shock absorber with its red protective boot.

SKU: RANRS5396 Category:

Specification

Shipping weight 7.00 lbs
Package dimensions 24.30 × 3.30 × 3.30 in
brands

Fitment

VehicleYearsTrims
Nissan Armada2005–2008LE, SE, SE Off-Road

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the RS5396 fit a 2005 Nissan Armada?

Yes. It fits the 2005 through 2008 Nissan Armada in LE, SE and SE Off-Road trim. A 2004 or 2009 model falls outside those years, so confirm your vehicle's year before you order.

What valving does the RS5396 use?

It uses ten-stage velocity sensitive valving, which changes damping force with shock speed. The piston rod is 5/8-in. (16mm) in diameter and the piston is 1 3/8-in. (35mm) in diameter.

Is the RS5396 a complete set?

No. It is a single rear shock absorber sold as each, so Armada owners replacing both rear shocks need two units. A red protective boot is included with each shock.

What is the RS5396 part number?

The part number is RS5396 and the UPC is 10039703002995. It belongs to Rancho's RS5000 Series, which Rancho says has been in use since 1985.

How often should Armada rear shocks be checked?

Check them at each oil change or tire rotation. Look for leaks, loose mounts and uneven tire wear. Heavy towing or off-road use calls for more frequent checks.
