Overview
The Gorilla Whips 6 ft LED Xtreme Whip with Wireless Remote (model LEDREM1000) is a 6 foot LED whip with over 215 LEDs for ATVs, RZRs, dune buggies, sand rails and UTVs. Its LEDs switch among 20 colors and 19 settings using a wireless remote that comes pre-synced to the whip.
The whip is a universal fit. The remote can link to other LED Xtreme Whips and Undermount kits.
Key features
- Over 215 LEDs on a 6 foot whip
- 20 built-in colors and 19 settings
- Remote pre-synced to this whip and linked to LED Xtreme Whips and Undermount kits from Gorilla Whips
- 40 in quick release wire harness with 2 quick connect wire splicers
- One quick release billet aluminum mount with quick release pin
Routing a longer whip
A longer whip puts more weight and flex on the mount, so the mounting point should be solid and free of movement. Choose a location that keeps the whip upright and clear of brush, and avoid spots where the whip could drag on rocks or get caught on trees during tight trail work.
Routing the harness is often the hardest part of installation. Keep the wire away from exhaust and hot components, pass it through grommets where it enters the cab or body, and leave a little slack at the mount so the wire does not pull at the connectors.
- Check the mount for movement after the first trail runs
- Use grommets where wiring passes through panels
- Leave slack at the mount, not at the connectors
- Keep the harness away from exhaust heat
Specifications
| Brand | Gorilla Whips |
|---|---|
| Model number | LEDREM1000 |
| UPC | 700007450291 |
| Length | 6 ft |
| LEDs | Over 215 |
| Colors | 20 |
| Settings | 19 |
| Wire harness | 40 in, quick release |
| Wire splicers | 2, quick connect |
| Hardware | 1-1/2 in bolt, nut, washer and lock washer |
| Mount | 1 quick release billet aluminum with quick release pin |
| Control | Wireless remote, pre-synced |
Vehicle fitment
It is a universal fit for ATVs, RZRs, dune buggies, sand rails and UTVs, so it is not vehicle-specific. Plan the mounting point on your own vehicle before installing.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The 6 foot length leaves more harness to route, so plan the path before fastening the mount. Run the harness through a fused circuit and check local rules before road use.
What’s included
One 6 ft LED whip with pre-synced wireless remote, 40 in quick release wire harness, 2 quick connect wire splicers, 1-1/2 in bolt, nut, washer and lock washer, and 1 quick release billet aluminum mount with quick release pin.
