FUEL Off-Road D746 Lockdown Wheel, 22x10 with 6 on 135 Bolt Pattern – Chrome – D74622008947

FUEL Off-Road

Shop FUEL Off-Road Wheels 22x10 on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • FUEL Off-Road D746 Lockdown 22×10 chrome aluminum wheel, part MHTD74622008947
  • 6 on 135 bolt pattern with 87 center bore
  • Listed offset of -18 and backspacing of 4.79
  • Fit is not tied to one make, model or year, so check before ordering.

Description

Overview

The FUEL Off-Road D746 Lockdown is a 22×10 aluminum wheel in a chrome finish, with a 6 on 135 bolt pattern and part number MHTD74622008947. It carries a listed offset of -18 and backspacing of 4.79, so its position against the hub and fenders should be checked before mounting.

Compatibility is not limited to one vehicle. The bolt pattern, center bore and offset are the measurements to match against your hub.

Key features

  • Chrome finish on aluminum construction
  • Directional style from the D746 Lockdown series
  • 22-inch diameter with a 10-inch width
  • 6 on 135 bolt pattern with an 87 center bore
  • Offset of -18 and backspacing of 4.79

Fitting a 22-inch chrome wheel

Larger wheels leave less sidewall for tire flex, so a 22-inch assembly passes more road shock to the suspension. Expect a firmer ride and check the tire’s load rating before mounting. Chrome faces also show chips from road debris, so pad the tire changer and use a soft cloth on the face.

Clearance is the first check. Turn the steering lock to lock with the tire mounted, and look for contact with the fender, caliper or sway bar. Recheck bolt torque after the first short drive, and inspect the wheel after any hard impact. Spacers or lift components change this geometry, so recheck clearance after any suspension change. A tire shop should also balance the full assembly before highway use.

Specifications

Brand FUEL Off-Road
Part number MHTD74622008947
Series D746 Lockdown
Style Directional
Finish Chrome
Construction Aluminum
Wheel diameter 22 Inches
Wheel width 10 Inches
Bolt pattern 6 on 135
Center bore 87
Offset -18
Backspacing 4.79
Fitment listed Universal Fit

Vehicle fitment

This wheel is not tied to one make, model or year. Match the 6 on 135 pattern, the 87 center bore and the -18 offset to your hub and wheel well.

Confirm your vehicle’s year, model and trim before ordering.

Installation notes

A -18 offset moves the wheel outward compared with a positive offset, so check clearance at the fender, brake caliper and suspension before mounting. A qualified installer should mount and balance the wheel before use.

What’s included

This entry covers the wheel only.

Not included: Plan for tires, lug nuts and center caps separately if your installation needs them.

SKU: MHTD74622008947 Categories: ,

Questions & Answers

Will the FUEL Off-Road D746 Lockdown 22x10 fit my vehicle?

Not confirmed for a specific vehicle. Compare the 6 on 135 bolt pattern, 87 center bore and -18 offset with your hub and wheel well, and check clearance against your vehicle before buying.

What is the part number of the D746 Lockdown wheel?

The part number is MHTD74622008947 and the series is D746 Lockdown. The wheel has a chrome finish and measures 22 inches in diameter by 10 inches wide, made of aluminum.

What offset and backspacing does it have?

The listed offset is -18 and the backspacing is 4.79. Offset and backspacing control where the wheel sits relative to the hub and fender, so compare both with your vehicle before mounting.

Are lug nuts, caps or tires included?

Only the wheel is covered here. Tires, lug nuts and center caps may be needed for your installation, so plan for them before mounting.

How often should a wheel be inspected?

Inspect the wheel at every tire rotation and after any hard impact. Look for cracks, bends, loose lugs and uneven tire wear, and address any problem before driving on rough terrain.
