Overview
The Fox 3.0 Factory Series Bypass Remote Reservoir Shock (part number 883-06-046) is a black and zinc finished shock absorber from Fox Racing Shox. It is built as a remote reservoir bypass design with DSC adjustment and a gas charged body, and Fox presents it as a direct replacement bolt-on shock.
Engineers designed each application to maximize suspension travel and performance on and off the road. The extended length is 27.53 inch, the collapsed length is 19.94 inch and the stroke is 7.59 inch. Confirm fit against your vehicle’s year, model and trim before ordering.
Key features
- Bypass design with a remote reservoir
- DSC adjustable setting
- Gas charged construction
- Black and zinc finish
- Extended 27.53 inch, collapsed 19.94 inch, stroke 7.59 inch
Remote reservoir bypass basics
A bypass remote reservoir shock moves the gas and oil reserve away from the shock body, which can help the body run with less heat buildup under sustained use. The reservoir needs its own mounting point and a hose route that stays clear of tires, brackets and moving suspension parts. Reservoir position also affects how well the hose is protected from debris, so plan that space before you start the installation.
DSC adjustment lets you change the compression setting, so the damping can match your driving style and terrain. Gas charged design keeps the shock working consistently when the oil heats up. Check the reservoir fittings, hose clamps and shock eyes for seepage and wear during routine inspections.
- Check hose clamps for cracks and looseness
- Keep the reservoir hose clear of heat sources
- Verify reservoir mount clearance before driving
Specifications
| Brand | Fox Racing Shox |
|---|---|
| Part number | 883-06-046 |
| UPC | 70000697179 |
| Series | Fox 3.0 Factory Series |
| Design | Bypass remote reservoir |
| Adjustment | DSC adjustable |
| Finish | Black/Zinc |
| Charge | Gas charged |
| Extended length | 27.53 inch |
| Collapsed length | 19.94 inch |
| Stroke | 7.59 inch |
Vehicle fitment
Direct replacement shocks of this type are made for many applications. Confirm fit for your year, model and trim before ordering.
Confirm your vehicle’s year, model and trim before ordering.
What’s included
The quantity and any parts beyond the shock itself are not confirmed. Verify the extra parts you need before starting the installation.
