Daystar 2 Inch Poly Flex Joint Kit – KU70007BK

Daystar

Shop Daystar Heim Joint Rebuild Kits on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Daystar KU70007BK, a 2 inch weld-on Poly Flex joint kit
  • Polyurethane-encased ball in a steel shell for quiet, wider-range pivoting
  • Serviceable and rebuildable; universal fit
  • Welded into your own links or brackets, so the joint itself is the only part supplied

Description

Overview

The Daystar KU70007BK is a 2 inch Poly Flex joint kit, a weld-on pivot joint for suspension and steering links that works as a quiet alternative to a traditional Heim joint. Like a Heim, it holds a spherical ball inside a steel outer shell. Daystar encases that ball in a special blend of polyurethane, which lets the joint move through a greater range without binding at its attachment points.

The polyurethane keeps the joint quiet over time, and the joint can be rebuilt rather than replaced. It is a universal fit component for custom builds, where the joint is welded into a link or bracket of your own design.

Key features

  • Spherical ball encased in polyurethane and held in a steel outer shell
  • Greater range of movement without binding at the attachment points
  • Quiet pivot that Daystar says does not make noise over time
  • Serviceable and completely rebuildable
  • Weld-on joint kit in a 2 inch size

Building a custom link

A pivot joint in a steering or suspension link has to handle angle changes as the axle cycles and the wheels steer. In a custom build, the joint is only as good as the link it sits in, so the tube wall, the bore and the weld penetration all matter. Clean the joint’s outer shell and the link bore before welding, and keep heat away from the polyurethane so the encased ball is not damaged.

Polyurethane joints wear differently from metal ones. Inspect the joint periodically for play, torn boots or cracked polyurethane, and check the link’s welds for hairline cracks where loads concentrate. Rebuilding the joint with new internals is usually easier than replacing a welded link, so keep service parts on hand for a long-term build. Careful fabrication and regular checks make a custom link last much longer under real load.

Specifications

Brand Daystar
Part number KU70007BK
UPC 814423017510
Joint style Weld-on joint kit
Joint size 2 inch
Type DOM
Maintenance Serviceable
Thread direction Not applicable

Vehicle fitment

It is a universal fit kit and is not built for one vehicle model. Fit depends on the link or bracket the joint is welded into. Check the 2 inch joint size and the bore of your link before ordering.

Installation notes

The joint is welded in place, so installation needs welding equipment and welding skills. Set the joint’s angle and position in the link before welding, because it cannot be repositioned afterward.

What’s included

The Weld-On Joint Kit, which is the Poly Flex joint itself.

Not included: the link, tube or bracket the joint is welded into.

SKU: DAYKU70007BK Category:

Specification

Shipping weight 1.00 lbs
Package dimensions 6.00 × 4.00 × 2.00 in
brands

Questions & Answers

Will the Daystar KU70007BK fit my Jeep?

It is a universal fit joint, so it is not built for a particular Jeep model. Whether it works depends on the link or bracket you weld it into, so check the 2 inch joint size and the bore of your link before you order.

Is a Poly Flex joint the same as a Heim joint?

Not exactly, but the two work on the same principle. Both use a spherical ball held in a steel shell. A Poly Flex joint encases the ball in polyurethane, which Daystar says allows a greater range of movement without binding and keeps the joint from making noise over time.

Does the kit include the link the joint is welded into?

No. The kit is the weld-on joint itself. The tube, link or bracket it is welded into is not included, so you will need to supply or fabricate that part before installing the joint.

How do I tell when the joint needs service?

Look for play at the pivot, a clicking or grinding sound, or polyurethane that is cracked or torn. Any of these means the joint should be serviced or rebuilt before the link goes back under load.
