Overview
The Crown Automotive 83505432 is a Dana 44 rear differential gear set with a locking design. The shaft is held by a roll pin.
The Dana 44 axle is the fitment basis, and no vehicle years or models are given. Confirm fit for your vehicle’s year, model and trim before ordering.
Key features
- Locking differential gear set
- Shaft is held by a roll pin
- Designed for the Dana 44 rear axle position
- Direct fit for the Dana 44 rear position
Pre-install checks
Gear sets for a Dana 44 rear are usually set up by an experienced shop, since pinion depth and backlash affect how long the gears last. Before the set goes in, inspect the carrier, bearing bores and axle seals for wear or damage, because a worn housing can undo good gears quickly.
A locking design changes how power reaches both wheels, so drive the vehicle gently after installation to check for unusual noise or binding in turns. The roll pin should sit fully seated before the axle is run, since a shifting pin can cause serious damage to the gears.
- Check the carrier for wear before installing
- Confirm the roll pin is fully seated
- Test for binding at low speed first
Specifications
| Brand | Crown Automotive |
|---|---|
| Part number | 83505432 |
| UPC | 848399026320 |
| Axle type | Dana 44 |
| Position | Rear |
| Design | Locking |
| Shaft retention | Roll pin |
Vehicle fitment
Dana 44 and the rear position are the fitment details, so check year, model and trim before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Gear sets generally call for professional setup and a break-in period, so have the set installed by someone experienced with differential work. Make sure the roll pin is fully seated before running the axle.
What’s included
A Crown Automotive Dana 44 rear differential gear set.
Not included: Check the package contents against your installation before starting. Plan to source any other parts the install requires.
