Overview
The ARB IPF 968 Series Driving Light Kit with Stone Guards, part 968CSG, is a multi-application driving light with a double reflector. The sub-reflector gives a broad fog beam in front of the vehicle, while the main reflector projects a driving beam far down the road. It has universal fitment.
The combined beams suit many driving situations. The lamp uses a 55 watt H3 bulb, and the kit includes an optional 100 watt bulb, behind a clear hardened glass lens.
Key features
- Double reflector: sub-reflector for a broad fog beam, main reflector for a driving beam
- 55 watt H3 bulb
- Optional 100 watt bulb included
- Clear hardened glass lens
- Round light shape with stem mounting
- Stone guards, as named in the title
Fog and driving beam use
A double reflector lamp splits its job between a broad fog beam and a long driving beam, which suits lower speed off road work as well as open roads. The sub-reflector spreads light close to the vehicle, so it helps on dusty or foggy tracks, while the main reflector reaches farther down the trail. Aim both beams together so the fog light does not glare back into the cabin.
Halogen H3 lamps produce considerable heat, which is why the choice between the 55 watt and 100 watt bulb affects wiring and mounting. Keep the glass and reflector clean, since mud and dust reduce the beam. Recheck bolts on the stem mount after the first few trips, and inspect the glass for cracks after rough runs.
Specifications
| Brand | ARB 4×4 Accessories |
|---|---|
| Part number | 968CSG |
| UPC | 700000479264 |
| Bulb type | Halogen |
| Bulb base type | H3 |
| Wattage | 55 watt, optional 100 watt included |
| Lens | Clear hardened glass |
| Light shape | Round |
| Mounting type | Stem |
| Fitment | Universal fit |
Vehicle fitment
Universal fitment applies, so no year, make or model is named. Choose the stem mount and placement to suit your bumper or bar, and check that the H3 bulb type matches your kit before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The choice between the 55 watt and 100 watt bulb affects heat and wiring, so confirm the bulb type before fitting. Use a fused relay and check local rules for driving and fog lights before road use.
What’s included
The kit includes a 55 watt H3 bulb, an optional 100 watt bulb, and stone guards.
Not included: A wiring loom, relay and switch are not included with the kit, so check the package contents against your installation before starting.
