Overview
The ARB Intensity V2 21 LED Spot Light, part number ARBAR21SV2, is a single round LED light with a spot beam, built for distance. It is universal fit, rated at 105 watts with 13170 lumens, and it mounts to a surface.
The spot optic in the Intensity V2 range uses what ARB calls HyperSpot technology, which the company describes as its latest optics for the spot configuration.
The spot optic in the Intensity V2 range uses HyperSpot technology, which focuses the light for distance. The light is engineered in Australia and manufactured in the United States, and the polycarbonate lens is designed to resist impact. It shares its housing design with the flood version.
The Intensity V2 is built on the same chassis design as the earlier Intensity range, with OSRAM LED technology. The light output is close to daylight in color.
Key features
- Round housing with a spot beam pattern
- 105 watts and 13170 lumens listed
- HyperSpot optics for focused distance lighting
- Polycarbonate lens
- LED light source with no warm-up time
- Submersible to 10 ft and compliant for radio interference suppression
- Vibration tested to military specifications
Aim and placement for distance
Mounting height and angle change how far a spot beam reaches, so placement matters as much as the optic itself. A light set low on a bar throws its hot spot close to the vehicle, while a higher, slightly downward aim reaches further along the track. Set the aim on level ground with the vehicle loaded as it normally is.
Because the beam is narrow, a spot does its best work with a flood beside it for the edges of the road. Keep the spot from overlapping the flood’s wider pattern too much, since that wastes light close in. Recheck the aim after any suspension or bar work, as small shifts move the hot spot a long way.
- Choose a height that suits your usual speed
- Level the vehicle before setting the aim
- Recheck alignment after suspension changes
Specifications
| Brand | ARB 4×4 Accessories |
|---|---|
| Part number | ARBAR21SV2 |
| Light series | Intensity V2 |
| Type | Driving light |
| Bulb type | LED |
| Light shape | Round |
| Watts | 105 watts |
| Lumens | 13170 lumens |
| Beam pattern | Spot |
| Mounting location | Surface |
| Sold as | Single |
| Fitment | Universal fit |
Vehicle fitment
It is universal fit and is not sized for a specific vehicle. The surface mounting location means the bracket and aim on your vehicle decide the final position.
Installation notes
Use a fused relay for this light, and check local rules on driving lights before using it on public roads. Because the spot beam is narrow, its placement matters more than it would for a flood.
What’s included
The package is one spot light, sold as a single unit.
Not included: wiring, a switch, a relay or a mounting bracket.
