Overview
The Rubicon Express TJ front sway bar mount, part number RE9992, is a pair of brackets for mounting a custom front axle in a Jeep TJ. The brackets are made for the 1997–2006 Jeep Wrangler TJ, and installation requires welding.
The brackets are laser cut from 3/16 inch cold rolled steel and CNC formed, which gives them a precise fit for custom axle mounting.
Key features
- Front sway bar mounts for a custom front axle
- Laser cut from 3/16 in cold rolled steel
- CNC formed for a precise fit
- Sold as a pair
- Bare steel finish
Before welding the brackets
Custom axle mounts put the axle’s load into the frame, so the brackets are only as good as the welds and the surface they sit on. Clean the frame area down to bare metal, check that the mounting points line up with the axle, and fit the brackets dry before any welding starts. Tack them in place and check alignment again before finishing the welds.
Steel brackets like these should be welded by someone who understands suspension loads and weld quality. Inspect the welds after the first trail outings, looking for cracks or distortion near the heat-affected area, and re-check the axle mounting fasteners at the same time. Protect the bare steel with paint or coating if the brackets will see moisture or salt.
- Measure the axle mounting points before cutting or drilling
- Clean all contact surfaces to bare metal
- Re-check welds after the first trail runs
Specifications
| Brand | Rubicon Express |
|---|---|
| Part number | RE9992 |
| UPC | 614901442533 |
| Axle location | Front |
| Material | 3/16 in cold rolled steel |
| Finish | Bare steel |
| Installation | Welding required |
| Quantity | Pair |
Vehicle fitment
Based on the product title and description, these front sway bar mounts are for the 1997–2006 Jeep Wrangler TJ. The TJ name does not cover the YJ, JK, JL or LJ.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The brackets are welded in place. Have the welding done by someone experienced with suspension brackets.
What’s included
A pair of front sway bar mounts.
Not included: the custom front axle the mounts are designed to hold.
