Overview
The Rigid Industries Truck-Lite 7 inch round LED headlight kit with PWM adaptors is a chrome, DOT compliant conversion for 7 inch round headlight housings. It is supplied as a pair and suits light, medium and heavy-duty trucks, off-road vehicles, classic cars and motorcycles.
The LED arrays produce a brighter, whiter light closer to daylight color temperature, with metalized reflector optics for a smooth, clean pattern. The solid state, bulb-free design is built to hold up against shock and vibration.
Key features
- 7 inch round LED conversion in chrome
- Two LED arrays
- Metalized reflector optics
- Hard-coated polycarbonate lens
- E-coat aluminum housing
- Encapsulated circuitry with 16 gauge wire
- PWM adaptors included
- DOT compliant
Wiring and relay setup
A relay is the usual way to run LED headlights, because it sends the full current straight from the battery and keeps the factory switch out of the load path. Route the wire away from heat, moving parts and sharp edges, and place a fuse close to the battery. Clean ground connections matter as much as the feed, since a weak ground can cause dim light and odd behavior.
PWM adaptors help LED lights work with a vehicle’s pulse-width circuits, but they do not replace good wiring. After installation, check that both lamps switch on and off together and that the beam aim is level. Recheck the connections after the first few drives, since vibration can loosen crimp terminals on rougher roads.
- Check the fuse and relay before first power-up
- Aim both lamps after mounting
- Inspect connectors regularly for looseness
Specifications
| Brand | Rigid Industries |
|---|---|
| UPC | 849774001734 |
| Size | 7 inches round |
| Color | Chrome |
| Light source | 2 LED arrays |
| Housing | E-coat aluminum |
| Lens | Hard-coated polycarbonate |
| Reflectors | Metalized |
| Wire | 16 gauge |
| Circuitry | Encapsulated |
| Included | PWM adaptors |
| Quantity | Pair |
| Warranty | 3 year limited lifetime |
| Fitment label | Universal Fit (see vehicle note below) |
Vehicle fitment
Fit depends on the housing size and mounting area on your vehicle, since this kit is a 7 inch round headlight conversion.
Confirm fit for your vehicle’s year, model and trim before ordering, and measure the housing size and mounting area first.
Installation notes
The kit includes PWM adaptors, 16 gauge wire and encapsulated circuitry. Wire it through a fused relay and check local road-use rules for headlight conversions before installing.
What’s included
A pair of 7 inch round chrome LED headlights with PWM adaptors, with a 3 year limited lifetime warranty.
Not included: Vehicle mounting hardware and a vehicle harness are not included.
