  • Front Rancho RS5000X Series strut assembly, part number RS55763
  • Fits 1996–2002 Toyota 4Runner and 1995, 2001–2002 Toyota Tacoma
  • Gas charged with progressive engagement valving and a 35mm bore
  • Limited lifetime warranty

Description

Overview

The Rancho RS55763 is a front strut assembly from the RS5000X Series for the 1996–2002 Toyota 4Runner and the 1995 and 2001–2002 Toyota Tacoma. It is a gas charged twin tube strut with progressive engagement valving and a tuned compression control valve.

The valving pairs a patented design with an advanced compression function that improves on-road and off-road handling. The strut is a direct fit for the front position.

Key features

  • Progressive engagement valving paired with a tuned compression control valve
  • Enlarged 2 1/4-in. twin tube body with gas pressurization
  • 16mm Nitro-Carburized rod on a full-displaced 35mm bore
  • 1 3/8-in. diameter sintered iron piston with glass-filled, Fluon banded design
  • Low-friction, self-lubricating seal and protective boot
  • Limited lifetime warranty

Gas charged struts on older trucks

Gas charged struts keep the oil from foaming when the piston moves rapidly, which helps damping stay steady during repeated hard use. On body-on-frame trucks, the front end sees more movement over rough roads, so a stable damper is useful. Gas pressure does not replace good valving; both work together to control the suspension.

Older trucks often have seals, bushings and mounts that have aged alongside the original struts. Replacing the strut without checking these parts can leave the front end feeling loose or noisy. A careful inspection before installation keeps the new strut working as intended.

  • Look for oil on the body or around the rod seal
  • Check the bushings and mounts for cracks
  • Inspect the boot for tears that let dirt in
  • Replace struts in pairs for balanced steering

Specifications

Brand Rancho
Part number RS55763
UPC 39703008556
Series RS5000X Series
Position Front
Fit type Direct fit
Shock type Gas charged
Valving Progressive engagement, tuned compression control valve
Tube body 2 1/4-in. enlarged twin tube
Bore 35mm full-displaced
Rod 16mm nitro-carburized
Piston 1 3/8-in. diameter sintered iron, glass-filled, Fluon banded
Seal Low-friction, self-lubricating
Bushings Black, natural rubber
Boot Protective
Loops Double-welded
Bumper Rebound bumper
Warranty Limited lifetime

Vehicle fitment

Rancho’s manufacturer fitment list covers these vehicles:

  • 1996–2002 Toyota 4Runner (Base, Limited, SR5)
  • 1995, 2001–2002 Toyota Tacoma (Base, Pre Runner, S-Runner)

The Tacoma is covered for 1995 and 2001–2002 only, so other Tacoma years are not covered. Confirm your vehicle’s year, model and trim before ordering.

What’s included

One strut assembly is supplied with a limited lifetime warranty. Check the package contents, including mounting parts, against your installation before starting.

SKU: RANRS55763 Category:

Specification

Shipping weight 7.20 lbs
Package dimensions 23.60 × 5.80 × 5.80 in
brands

Fitment

VehicleYearsTrims
Toyota 4Runner1996–2002Base, Limited, SR5
Toyota Tacoma1995, 2001–2002Base, Pre Runner, S-Runner

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the RS55763 fit a 2001 Toyota Tacoma?

Yes. The manufacturer fitment list includes the 2001–2002 Toyota Tacoma in the Base, Pre Runner and S-Runner trims. Confirm your vehicle's year, model and trim before ordering, because Tacoma years outside that range are not on the list.

Is this strut gas charged?

Yes. It is gas charged, with a 35mm full-displaced bore, a 16mm nitro-carburized rod, and progressive engagement valving paired with a tuned compression control valve.

Does the RS55763 include mounting hardware and a warranty?

It includes a limited lifetime warranty. Check the package contents, including any mounting parts, against your existing strut before installation, and confirm fit for your vehicle's year, model and trim.

What does progressive valving do?

Progressive valving increases damping resistance gradually as piston speed rises. Slow movements stay comfortable, while faster hits are controlled more firmly, which helps the truck stay steady over rough roads without a harsh ride on smooth pavement.

Should both front struts be replaced together?

Usually yes. Replacing both fronts keeps steering and ride height consistent from side to side. A new strut beside a worn one can pull toward the old side, so compare both units before deciding.
