Overview
The Rampage Front and Rear Bumper Package (Black), part number 78510615K, is a matched pair of steel recovery bumpers: a front bumper with a stinger and a rear bumper with a tire carrier. It has a textured black powder coat finish and includes the Rampage front bumper #RPP78510 and rear bumper #RPP78615.
The bumpers are built for off-road use and rock crawling, with custom welded shackle mounts, 3/4″ shackle d-rings and a 3/16″ steel plate design with two 4″ light openings. The rear tire carrier holds up to a 35″ tall tire, and the finish is a textured black powder coat.
Key features
- Front bumper with stinger and rear bumper with tire carrier
- Textured black powder coat, a dual stage finish
- 3/16″ steel plate design
- Custom welded shackle mounts with 3/4″ shackle d-rings
- Includes 4 d-rings
- Two 4″ light openings on both bumpers (lights sold separately)
- Rear tire carrier holds up to a 35″ tall tire with a heavy-duty latch and hinge
- Includes a Trail Can Utility Tool Box
Winch and light planning
A front bumper with a stinger is often the place a winch goes, so think about where the winch line will run before mounting the bumper. Winch placement affects the approach angle and how the stinger handles brush. Confirm the mounting plate and bolts are sound before loading the winch, since shock loads go straight into the bumper.
The two light openings on each bumper need lights and wiring that suit the openings, and wiring should run through protected routes with a fuse close to the battery. Light placement affects visibility and glare, so aim lights after the bumper is fully installed. Re-check all wiring after the first off-road trip. Guards and cameras should also be checked for clearance.
- Plan winch line routing before mounting
- Fuse all added lights and accessories
- Re-aim lights after installation
Specifications
| Brand | Rampage |
|---|---|
| Part number | 78510615K |
| UPC | 70000676019 |
| Product type | Front and rear bumper package |
| Included bumpers | Front #RPP78510 and rear #RPP78615 |
| Finish | Textured black powder coat |
| Material | Steel |
| Plate | 3/16″ steel plate |
| Width | Full |
| Winch mount | Included |
| Light mounts | Included; two 4″ light openings on both bumpers |
| D-ring mounts | Included |
| D-rings | 4, with 3/4″ shackle d-rings |
| Rear tire carrier | Holds up to a 35″ tall tire |
| Fitment type | Universal fit (no vehicle listed) |
Vehicle fitment
This package is a universal fit design with no make, model or years named. Bumpers attach to a specific frame and body, so fit has to be confirmed for your vehicle before ordering.
Do not assume fit from the universal-fit designation alone. Check mounting points, rear carrier clearance and your vehicle’s year, model and trim before ordering.
Installation notes
Tighten all fasteners fully and support the vehicle on jack stands or a lift on level ground, never on a jack alone. Re-check fastener tightness after the first miles of driving.
Bumpers are heavy, so use a second person or a lift to position them. After installation, check that any lights, cameras and sensors still work and that nothing contacts the tires at full steering lock.
Check the rear tire carrier for the largest tire it holds (35″ tall), and make sure the latch is secure before driving.
A winch added to the front bumper needs its own wiring and fusing, so follow the winch’s own installation steps.
What’s included
A front bumper with a stinger and a rear bumper with a tire carrier, 4 d-rings with 3/4″ shackle mounts, and a Trail Can Utility Tool Box. The package includes bumpers #RPP78510 and #RPP78615.
Not included: lights, which are sold separately, and a winch.
