Oracle Lighting Underbody Rock Light Kit (4-Piece) – 5796-333

Oracle Lighting

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Four-piece underbody rock light kit with ColorSHIFT color control
  • Three 3W Cree LEDs per module, 150 degree emitting angle
  • Powder coat aluminum housing with IP68 rating
  • Waterproof connections and 9-32V input
  • Bluetooth app control, with a 2-year warranty

Description

Overview

The Oracle Lighting Underbody Rock Light Kit (4-Piece, part 5796-333) is a set of four oval LED rock lights for off-road use. Oracle designed the modules to be installed in the wheel wells in front of and behind each tire, which Oracle says gives the driver better visibility over rocks, mud, water and sand. Each module uses three 3W Cree LEDs with a 150 degree emitting angle.

The kit is designed for a wide range of 4×4 off-road vehicles, including Jeeps and trucks, and the modules mount in the wheel wells rather than to a specific vehicle part. The housings are powder coated aluminum rated IP68, the connections are waterproof, and the wiring is heavy gauge. The lights run on a 9-32V input.

Key features

  • ColorSHIFT technology for thousands of colors
  • Bluetooth app control of color, brightness and strobing
  • Create and select DIY light scenes
  • Music sync function
  • Three 3W Cree LEDs per module
  • Powder coat aluminum housing rated IP68
  • Waterproof connections and heavy gauge wiring

Before you install underbody lights

Underbody rock lights take the same mud, water, rock strikes and debris as the rest of the lower body, so wiring and mounting points matter as much as the light itself. Before installing, look at how the modules sit in the wheel wells and whether the wire can run clear of steering, axle and suspension travel. A wire that is pinched or rubbing against a tire or control arm is one of the most common causes of underbody light failure, so secure the harness with clips and leave some slack at each joint.

Power matters too. Because the kit can be controlled from a phone, it draws power whenever the switch is on, so wire it to a switched circuit with a fuse and avoid tapping into systems that carry critical loads. Lights used on night trails are often left on for long periods, so check connectors for corrosion regularly and keep the lenses clean so the light output stays consistent.

  • Route wiring away from moving suspension parts
  • Check connectors for corrosion periodically
  • Clean lenses after muddy trips

Specifications

Brand Oracle Lighting
Part number 5796-333
UPC 579633320163
Light type LED rock light, oval, 4 pieces
LEDs 3 x 3W Cree per module
Input voltage 9-32V
Emitting angle 150 degree maximum
Housing Powder coat aluminum
Ratings IP68 waterproof
Color Multi-color (ColorSHIFT)
Control Bluetooth app for Android or iOS, free to download
Warranty 2 year

Vehicle fitment

Oracle lists these rock lights as universal fit. Oracle says they fit virtually any 4×4 off-road vehicle, Jeep or truck, and they mount in the wheel wells rather than to a specific vehicle part. Measure the wheel well clearance and wire routing on your vehicle before ordering, because the modules sit close to the tires.

Installation notes

The modules mount in the wheel wells, so route the wiring away from moving suspension parts and use the waterproof connections. Power the kit through a fused circuit, and check local rules for underbody lighting before use on public roads.

What’s included

Four rock light modules with brackets, waterproof connections and the Bluetooth control setup described in the specifications.

SKU: ORC5796-333 Category:

Specification

Shipping weight 4.00 lbs
Package dimensions 8.00 × 5.50 × 5.10 in
brands

Questions & Answers

Is the Oracle 4-piece rock light kit sold as a full kit?

Yes. The 4-piece set includes four rock light modules with brackets and waterproof connections. Oracle also sells an 8-piece version of the same kit for larger coverage.

Can the lights be controlled from a phone?

Yes. The kit works with a Bluetooth app for Android or iOS, which is free to download. The app controls color, brightness and strobing, and it can create and select DIY light scenes for the four modules.

Does the Oracle rock light kit have a warranty?

Yes. The 4-piece kit carries a 2 year warranty. The modules use waterproof construction and an IP68 rating, and the connections are waterproof as well, so the kit is built for wet off-road use.

How do I keep underbody lights working after trail use?

Rinse the modules and connectors after muddy runs and inspect the wiring for chafing at each clip. Look for corrosion on the waterproof connectors and make sure the seals remain seated. Regular checks catch small problems before they become a failed light out on the trail.
