Overview
The FUEL Off-Road D576 Assault 20×10 is a mesh-style aluminum wheel with a 5 on 5.5 bolt pattern and part number MHTD57620007047. It has a black finish, a 110 center bore, an offset of -18 and backspacing of 4.8.
Bolt pattern and center bore decide whether a hub accepts this wheel, so measure both before buying.
Key features
- Mesh style
- 5 on 5.5 bolt pattern
- Aluminum construction in a black finish
- Offset -18 with 4.8 backspacing
Offset and backspacing basics
Offset and backspacing describe where the wheel mounting face sits relative to the hub and the inner barrel. A negative offset pushes the wheel outward, which can change tire position near the suspension. Backspacing shows how far the inner barrel reaches toward the brakes, so both figures matter when clearance is tight.
Before you mount a wheel with these figures, compare the inner barrel with the caliper and the suspension arm. Tire size also changes how far the tire moves outward, so a test fit with the tire you plan to run is the most useful check.
- Measure the distance from the hub face to the caliper
- Check tire sidewall clearance at full steering lock
- Look at the shock and control arm positions
- Use spacers only with a known hub and bolt length
Specifications
| Brand | FUEL Off-Road |
|---|---|
| Part number | MHTD57620007047 |
| Model | D576 Assault |
| Wheel diameter | 20 inches |
| Wheel width | 10 inches |
| Bolt pattern | 5 on 5.5 |
| Center bore | 110 |
| Offset | -18 |
| Backspacing | 4.8 |
| Style | Mesh |
| Finish | Black |
| Construction | Aluminum |
Vehicle fitment
Fitment is open for this wheel. Use the 5 on 5.5 bolt pattern and 110 center bore as the first filter for your hub.
Compare offset and backspacing with the clearance you need before ordering. Confirm your vehicle’s year, model and trim before ordering.
What’s included
Only the wheel is included. Lug hardware and center caps are not included.
