Overview
The Fab Fours GM14-C3151-1 is a front winch bumper with sensor holes and no guard for the 2015 to 2018 GMC Sierra 2500 HD and 3500 HD. It is steel with a black powder coat and has a winch tray for winches up to 16,500 lb.
Fab Fours says its Premium winch bumpers have a redesigned center section with four integrated sensor holes for factory equipped sensors. The holes are laser cut to the factory pattern and compatible with the OEM sensor housing, so both the front and the matching rear steel bumpers work with factory park assist.
The internal winch tray has a new D-ring and fairlead location, and access slots in the lower portion let the factory sensor harness pass through.
Key features
- No-guard winch bumper with sensor holes for 2015 to 2018 GMC Sierra 2500 HD and 3500 HD
- Four laser cut sensor holes in the factory pattern
- Compatible with the OEM sensor housing
- Access slots in the winch tray for the factory sensor harness
- Winch ready for winches up to 16,500 lb
- 3/4-inch D-ring mounts
- 90mm fog lights and 60mm turn indicators included
- Adjustable 1/4-inch boxed mounting system
- Made in the USA
Choosing a no-guard winch bumper
A no-guard winch bumper keeps the front face open, which suits drivers who want a cleaner look and easy access to the radiator area. Without a guard, the lower face takes more direct hits from rocks and brush, so the bumper’s steel and powder coat need regular checks. The winch tray and sensor holes do the main work, so keep those areas clear and dry.
Think about how you use the truck. For mostly road driving, the open face is easy to keep clean. For trail use, consider adding a separate skid plate or guard if the lower edge sees heavy rock contact. When the sensor option is used, keep the harness path clear, and after any bodywork check that the sensor housings still sit square in their holes. Replace worn cable and fairleads before recovery, since a frayed line is the usual cause of trouble.
Specifications
| Brand | Fab Fours |
|---|---|
| Part number | GM14-C3151-1 |
| UPC | 5810109509 |
| Product type | Front winch bumper with sensor holes, no guard |
| Position | Front |
| Width | Full |
| Material | Steel, 1/4-inch and 3/16-inch combination |
| Finish | 2 stage matte black powder coat |
| Winch capacity | 16,500 lb winch or smaller |
| D-ring mounts | 3/4-inch |
| Lights | 90mm fog lights and 60mm turn indicators |
| Sensor holes | Four, laser cut, factory pattern |
| Winch mount | Included |
Vehicle fitment
It is a direct-fit front bumper for the 2015 to 2018 GMC Sierra 2500 HD and 2015 to 2018 GMC Sierra 3500 HD.
Sierra 1500 trucks and older heavy duty generations are not covered by this part. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The sensor harness passes through access slots in the lower winch tray. The adjustable boxed mounting system lets the fit be set to preference.
What’s included
- Front winch bumper without guard
- Winch mount
- 90mm fog lights
- 60mm turn indicator lights
- Sensor holes cut to the factory pattern
Not included: The winch, the factory sensors and wiring.
