Overview
The Energy Suspension universal shock eyes, title code 9.8126G, are polyurethane shock bushings with a bayonet end style for shock tower mounting. They are sold as universal fit, so they are not built for one specific vehicle.
Energy Suspension describes its polyurethane shock bushings and grommets as long-lasting and says they add to shock performance. The eye has a 5/8 in. nipple, a 3/8 in. inside diameter and 5/8 in. thickness, and four grommets are included.
Key features
- Polyurethane construction for shock bushings and grommets
- Shock tower bayonet end style
- 5/8 in. nipple with 3/8 in. inside diameter
- 5/8 in. thick
- Four grommets included
- Black finish
Choosing a shock eye
A shock eye is the bushing at each end of a shock absorber, sitting between the shock body and its mounting bracket. It isolates road vibration from the frame and lets the shock pivot as the suspension moves. When the bushing wears, the shock can knock, drift or develop play at the mount, which often shows up as a loose feel on rough roads.
Choosing a replacement starts with the shock itself. Check the end style, the nipple length and the inside diameter of the eye you are removing, and compare them with the new part before forcing anything. Polyurethane is firmer than rubber, so it passes more vibration into the mount, yet it holds its shape well under repeated load. Replace grommets as a set so the new eye seats square in the bracket.
Inspect shock eyes at every service. Look for cracks, flattening or a grommet that has shifted out of position. Tighten fasteners firmly when reassembling and recheck them after the first few trail runs.
- Cracks or flattening around the bushing
- Play at the mount when the shock is lifted
- Grommets that have pulled out of their seat
Specifications
| Brand | Energy Suspension |
|---|---|
| Part number | Not listed (title code 9.8126G) |
| UPC | 703639415305 |
| Style | Universal shock eye, bayonet end |
| Material | Polyurethane |
| Nipple diameter | 5/8 in. |
| Inside diameter | 3/8 in. |
| Thickness | 5/8 in. |
| Grommets | 4 |
| Finish | Black |
Vehicle fitment
It is a universal fit shock eye, so it is not tied to a specific year, make or model.
Confirm fit for your vehicle’s year, model and trim before ordering. Match the bayonet end style and eye size to your shock before buying.
What’s included
Four grommets are included with the shock eyes.
Not included: Shock absorbers are not included.
