Overview
The Energy Suspension 9.8101R is a red universal shock eye in the shock tower bayonet end style, with a 7/8 in. nipple and 4 grommets. Polyurethane construction and a universal fit are listed, so the eye is not tied to a particular vehicle.
Energy Suspension says its polyurethane bushings and grommets add to shock performance, and this red eye includes four grommets for that purpose.
Key features
- Bayonet end for shock tower mounts
- 7/8 in. nipple
- Polyurethane construction
- 4 grommets included
- Inside diameters of 3/8 in. and 5/8 in.
- Red finish with 5/8 in. thickness
Shock tower bayonet mounts
Bayonet-style eyes seat into a tower mount and are held in place by the nipple, which makes the seating depth and nipple diameter important. A snug fit keeps the shock aligned and limits the movement that wears the grommets. Compare the old eye’s nipple and thickness with the new one before removing the shock, so you know what to expect when reinstalling.
Grommets absorb repeated flex, so they are usually the first parts to show wear in this kind of mount. Inspect them during routine service for hardening, cracks or flattening. Clean the tower area of trail debris before fitting, and tighten the nipple retainer to the point where the shock moves without play but still swings freely.
- Compare the nipple with the old eye before removal
- Inspect grommets for hardening or cracks
- Clean the tower area before fitting
Specifications
| Brand | Energy Suspension |
|---|---|
| Part number | 9.8101R |
| UPC | 703639414056 |
| Style | Shock tower bayonet end |
| Nipple | 7/8 in. |
| Inside diameter (ID) | 3/8 in. and 5/8 in. |
| Thickness | 5/8 in. |
| Included | 4 grommets |
| Color | Red |
| Material | Polyurethane |
| Fitment | Universal fit |
Vehicle fitment
Universal fit, so this eye is not designed around one make, model or year. Check the bayonet end and 7/8 in. nipple against your shock tower before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Compare your current eye’s nipple and thickness with the figures listed above before fitting.
What’s included
Four grommets come with the eye. No other parts are included.
