Overview
The Daystar PAFL223PA is a 2-inch coil spring leveling system that includes passenger and driver shock extensions. The kit also includes a brake line bracket, an upper brake at frame bracket and an ABS sensor bracket, along with hardware. It is a direct fit design, so the vehicle application should be checked before buying.
Key features
- 2-inch coil spring leveling
- Passenger and driver shock extensions
- Brake line and upper brake at frame bracket
- ABS sensor bracket
Brake and shock work
Shock extensions lengthen the shock mounting so the shock works with the raised spring height. A longer shock changes the damping range and can alter the feel over bumps, so the stock shock’s travel should be considered. The brake line bracket and ABS sensor bracket move components that are normally fixed, which places more demand on the brake lines and sensor wiring.
After installation, check the brake hose for twisting or tension at full suspension travel. Confirm the ABS sensor wire has enough slack, and recheck brake function before driving at speed. Any light brake pedal change after installation should be treated as a reason to stop and inspect the work. Keep the hardware sorted by location to simplify reassembly.
- Check brake hose routing at full droop
- Confirm the ABS wire has enough slack
- Test brakes at low speed before highway use
Specifications
| Brand | Daystar |
|---|---|
| Part number | PAFL223PA |
| UPC | 618089008482 |
| Lift | 2 inches |
| Suspension type | Coil spring leveling |
| Shock extensions | Passenger and driver |
| Fitment type | Direct fit |
Vehicle fitment
Check the vehicle year, model and trim against this kit before buying.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The kit relocates a brake line and an ABS sensor bracket, so the brake lines and sensor wiring should be checked during installation. The shock extensions change the shock length.
What’s included
- Passenger shock extension
- Driver shock extension
- Brake line bracket
- Upper brake at frame bracket
- ABS sensor bracket
- Hardware
