Overview
The Crown Automotive J3241239 is a shift lever clip for the 2002 Jeep Liberty (KJ). It pairs with an NP231 transfer case and a T4 or T5 manual transmission.
The clip belongs to the shift mode synchronizer assembly group and is a direct fit for the application above. Compare the year and transfer case against your vehicle before installing.
Key features
- Shift lever clip for the 2002 KJ Liberty
- Listed with an NP231 transfer case
- Listed with a T4 or T5 manual transmission
- Part number J3241239 with UPC 848399061284
Shift linkage and clip wear
A shift lever clip holds a link or retainer in place so the shifter moves the selector without play. When the clip loses tension, the lever can wander, the shift feel becomes vague, and in worst cases the linkage can disconnect under load. The clip is inexpensive, so it is often replaced during a shifter rebuild or when a worn linkage bushing is found.
Look for bent tabs, cracks, rust, or a clip that no longer snaps firmly onto its pin. Inspect the pivot, the bushing and the selector arm at the same time. Lubricate the pivot with a light grease, and do not reuse a clip that has been stretched during removal. Clips used in this application work with the NP231 and T4 or T5 setup, so keep the old clip until the new one is confirmed to seat.
Specifications
| Brand | Crown Automotive |
|---|---|
| Part number | J3241239 |
| UPC | 848399061284 |
| Vehicle listed | 2002 KJ Liberty |
| Transfer case | NP231 |
| Transmission | T4 or T5 manual |
| Category | Shift Mode Synchronizer Assembly |
Vehicle fitment
Fitment is for a 2002 KJ Liberty with an NP231 transfer case and a T4 or T5 manual transmission. Check those three details against your vehicle.
Other Liberty years and other transfer case or transmission combinations are not covered. Confirm fit for your vehicle’s year, model and trim before ordering.
What’s included
Check the package contents, including the number of clips, against your installation before starting.
