California Supertrucks 2.0 Reservoir Shock – CSR-6534

California Super Trucks

Shop GMC Sierra 2500 HD Shock Absorbers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Fits 2011–2018 Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD
  • Front gas charged shock with a 2.0 reservoir
  • Fits lifts from 3 to 6 inches.
  • Bushing mounts, so manufacturer-installed Heim joints do not need to be pressed out
  • Required hardware included, per the manufacturer

Description

Overview

The California Super Trucks CSR-6534 is a gas charged 2.0 reservoir shock absorber for the front suspension of 2011–2018 Chevrolet Silverado 2500 HD and 3500 HD and GMC Sierra 2500 HD and 3500 HD trucks. It is a front-position shock built for lifted trucks with a 3 to 6 inch lift range, and it is sold under the California Super Trucks brand.

The CSR-6534 is built in the U.S.A. It uses bushing mounts instead of the factory Heim joints, so the factory Heim joints do not need to be pressed out during installation. Confirm the lift setting matches your current suspension before ordering.

Key features

  • Gas charged shock with a 2.0 reservoir
  • Front position for lifted heavy-duty trucks
  • Listed lift range of 3 to 6 inches
  • Bushing mounts, so manufacturer-installed Heim joints do not need to be pressed out
  • Required hardware is included.
  • Built in the U.S.A. by California Super Trucks.
  • Direct fit for the listed 2011-2018 Silverado and Sierra 2500 HD and 3500 HD trucks.

Front shock setup for lifted trucks

Bushing mounts and Heim joints both connect the shock to the truck, but they behave differently over time. Bushings are quieter and simpler to install, while Heim joints can allow more articulation and are common on off-road builds. Whichever type you choose, confirm the mount style before ordering so the hardware on the truck matches.

A reservoir shock places its gas chamber in an external tube, which helps it stay cool during repeated hard strokes. Front shocks carry much of the steering load, so worn mounts or tired bushings can cause vague steering and uneven tire wear. Replace bushings when they crack, flatten or develop play, and recheck torque after the first drives.

  • Inspect the reservoir hose for kinks
  • Check the bushing sleeves for movement
  • Retorque mounting bolts after the first drives

Specifications

Brand California Super Trucks
Part number CSR-6534
UPC 700007379811
Position Front
Shock type Gas charged, 2.0 reservoir
Lift range 3 to 6 in
Mounting Bushings (no Heim joints)
Fitment type Direct fit
Country built U.S.A. (per manufacturer)

Vehicle fitment

It fits 2011–2018 Chevrolet Silverado 2500 HD (High Country, LT, LTZ, WT), 2011–2018 Chevrolet Silverado 3500 HD (High Country, LT, LTZ, WT), 2011–2018 GMC Sierra 2500 HD (Base, Denali, SLE, SLT, WT) and 2011–2018 GMC Sierra 3500 HD (Base, Denali, SLE, SLT, WT).

Standard-duty 1500 models and years outside 2011–2018 are not in this list. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

Because the shock uses bushing mounts and includes its hardware, the factory Heim joints do not need to be pressed out. Support the truck on stands before removing the old front shock, and confirm the lift range suits your current lift height.

What’s included

One front 2.0 reservoir gas charged shock with the required hardware.

Not included: This item covers one front shock position.

SKU: CSTCSR-6534 Category:

Specification

Shipping weight 9.00 lbs
Package dimensions 39.00 × 6.00 × 3.00 in
brands

Fitment

VehicleYearsTrims
Chevrolet Silverado 2500 HD2011–2018High Country, LT, LTZ, WT
Chevrolet Silverado 3500 HD2011–2018High Country, LT, LTZ, WT
GMC Sierra 2500 HD2011–2018Base, Denali, SLE, SLT, WT
GMC Sierra 3500 HD2011–2018Base, Denali, SLE, SLT, WT

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Will the CSR-6534 fit a Silverado 1500 or Sierra 1500?

No. It fits only 2011–2018 Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD models, so standard-duty 1500 trucks are not covered. Confirm your vehicle's year, model and trim before ordering.

Is the CSR-6534 a gas charged shock?

Yes. It is a gas charged shock with a 2.0 reservoir design in the front position. Its bushing mounts mean the factory Heim joints do not have to be pressed out during installation, and it is built for the trucks in the fitment coverage.

What lift height range is the CSR-6534 built for?

It fits lifts from 3 to 6 inches. Match that range to your current suspension height before ordering, and confirm the setting before installation.

Who builds the CSR-6534?

It is built in the U.S.A. by California Super Trucks, the brand behind its street-series, dirt-series and pro-series shocks. The part number is CSR-6534, so use that number when comparing it with other shocks.

Are bushing mounts better than Heim joints?

Neither is better in every case. Bushing mounts are quieter and need no pressing, while Heim joints allow more articulation and are often used in off-road setups. Choose based on how the truck is used and whether the joints wear out.
