Overview
The Warn Series 15DC 15,000 lb industrial winch, part number 66032, is a 12V DC winch for heavy-duty industrial and recovery work. It has a 3.8 hp high torque motor, a 315:1 gear ratio and a 32′ (10m) industrial remote control.
The control pack is weatherproof and built around an industrial contactor. A disc brake is designed for extended power-out use, and a thermal overload switch protects the motor from overheating. The 24V version of this winch is listed under PN 65932. Warn lists compliance with SAE J706, NFPA 1901-73 and the CE Machinery Directive 98/37/EEC.
Key features
- Pulling capacity up to 15,000 lbs.
- 3.8 hp high torque motor, 12 or 24 volt DC series wound
- Weatherproof industrial contactor control pack
- Rugged 32′ (10m) industrial remote control
- Disc brake designed for extended power-out use
- Thermal overload switch protects the motor from overheating
Duty cycles and industrial use
Industrial winches are often run in short, repeated cycles, and the duty cycle matters as much as the rated load. A motor that runs continuously for long periods builds heat, so allow rest time between pulls and watch the housing temperature. The thermal overload protection helps, but it is a safeguard rather than a substitute for sensible operating habits.
The contactor and control pack take the most abuse from moisture and dust on job sites. Keep the enclosure closed, inspect the seals and cable jackets, and replace any remote lead that shows cuts. A weatherproof control pack only stays weatherproof while its gaskets and fittings are intact.
- Allow rest time between heavy pulls
- Keep the control pack enclosure closed
- Replace remote leads that show cuts
Specifications
| Brand | Warn |
|---|---|
| Part number | 66032 (12V); PN 65932 (24V) |
| UPC | 1274866032 |
| Winch type | Industrial |
| Maximum rated load | 15000 lbs. (6818 kg) |
| Maximum wire rope recommended | 1/2 |
| Minimum breaking strength of recommended rope | 26600 lbs. (12091 kgs.) |
| Drum barrel diameter | 4.0 (102mm) |
| Drum flange diameter | 8.24 (209mm) |
| Distance between flanges | 9.95 (253mm) |
| Gear ratio | 315:1 |
| Motor | 12 or 24 volt DC series wound, 3.8 hp (2.83 kw) |
| Contactor | Industrial contactor with 32′ (10m) heavy duty remote control |
| Line type | Wire |
| Standards | SAE J706, NFPA 1901-73, CE Machinery Directive 98/37/EEC |
Vehicle fitment
The winch is a universal fit unit. Mounting position, voltage and rope length should be checked against the equipment it is installed on.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Match the 12V part number 66032 or the 24V part number 65932 to the electrical system before wiring. The 3.8 hp motor draws considerable current, so use fused battery leads sized for that load. Keep hands and loose clothing away from the rope and drum whenever the winch is pulling.
What’s included
The industrial contactor and the 32′ (10m) heavy duty remote control come with this winch.
Not included: Wire rope and mounting hardware are not part of the package.
