Overview
The KC HiLites 6 Inch Round Daylighter Kit, model 237, is a chrome 6 inch round halogen spot light kit with a 100 watt bulb, universal fit. It is a long-range light built on a chrome-plated steel housing with a stem mount, and the kit is sold with all the hardware and wiring needed for installation. The spot beam is rated at 200,000 candlepower.
Key features
- 100 watt quartz halogen bulb in a long-range spot pattern
- Chrome-plated steel housing
- Rubber-mounted bulb to dampen vibration
- Illuminated switch included
- Two hard plastic yellow KC light covers
- Clear round lens
Halogen spot lights and heat
Halogen spot lights throw a focused beam that reaches far down the trail, which suits open terrain and long straights. Because the bulb runs hot, the mounting position should leave room for airflow and keep the housing away from fuel lines, wiring looms and plastic trim. A spot pattern is most useful when the light is aimed at the area you need to see, not used as a general work light.
Care is simple but important. Keep the lens clean, since dirt reduces output, and check the bulb and mount after rough trips. Use the illuminated switch to turn the light off when parked, and avoid running the light for long periods with the engine off, which can drain the battery.
Specifications
| Brand | KC HiLites |
|---|---|
| UPC | 8470900237 |
| Light type | Driving / spot light kit, sold as a kit |
| Light shape | Round, 6 inch |
| Lens color | Clear |
| Bulb type | Quartz halogen, 100 watt |
| Housing | Chrome-plated steel |
| Beam pattern | Spot, long range |
| Candlepower | 200,000 cp |
| Mounting | Stem mount |
| Included | Light covers (2, hard plastic, yellow) |
Vehicle fitment
The kit is not built for a specific vehicle, so the mounting position and wiring route depend on where the light goes. Check the mount location before ordering.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
The kit includes all necessary hardware and wires, along with instructions. Halogen bulbs run hot, so keep the housing and wiring clear of heat sources, and run the lights through a fused relay and switch as the instructions show.
What’s included
One 6 inch chrome round halogen spot light with stem mount, all necessary hardware and wires, an illuminated switch, two hard plastic yellow light covers, and instructions.
