Overview
The KC HiLites 4-inch Gravity LED fog light system, part 495, is a set of round 4-inch LED fog lights rated at 20W total, with a white lens and bracket mounting. It meets SAE (US) and E-Mark/ECE (Europe) street legal specifications. It is a universal fit for Jeeps, trucks, SUVs and similar vehicles.
The system includes everything needed to mount the performance LEDs on a Jeep, truck or SUV. It is a pair of 4-inch Gravity LED fog lights, a complete set for two mounting positions.
Key features
- Street legal, meeting SAE (US) and E-Mark/ECE (Europe) specifications
- Pair of 4-inch Gravity LED fog lights totaling 20W
- White lens with LED bulb
- Round light shape with bracket mounting type
- Includes everything needed for installation
Wiring and fog light use
Fog lights draw a steady load, so run them through a fused relay wired directly to the battery or a switched source rather than the factory switch circuit. This keeps the wiring cooler and protects the vehicle’s electrical system. Use a relay rated for the total current of the pair, and route the harness away from moving suspension parts and heat sources.
Aim and placement matter as much as wiring. Mount the lights low enough to keep the beam under the level of oncoming traffic, and set the aim after the vehicle is loaded the way you usually drive. Check the bracket and hardware after the first few trips on rough roads, since vibration can loosen fasteners. Seal every connector at the bumper so water and road grime stay out of the terminals.
- Fused relay sized for the pair
- Weatherproof connectors at the bumper
- Harness routed away from heat and moving parts
Specifications
| Brand | KC HiLites |
|---|---|
| Part number | 495 |
| UPC | 84709004958 |
| Light diameter | 4 inches |
| Power | 20W total for the pair |
| Lens color | White |
| Bulb type | LED |
| Light shape | Round |
| Mounting type | Bracket |
| Standards | SAE (US), E-Mark/ECE (Europe) |
| Fitment type | Universal fit |
Vehicle fitment
It is a universal fit for Jeeps, trucks and SUVs. Confirm mounting position and clearance for your vehicle’s year, model and trim before mounting.
Check the lights against your bumper or bracket location before mounting, since the system is not matched to a specific vehicle.
Installation notes
Run the wiring through a fused relay, as is standard for LED lighting of this power. Check local regulations for fog lights before driving with them lit on public roads.
What’s included
A pair of 4-inch Gravity LED fog lights with everything needed to install them.
The kit is a pair of lights. Confirm the quantity in your order before installing.
