California Supertrucks 2.0 Reservoir Shock – CSR-6525

California Super Trucks

Shop GMC Sierra 3500 HD Shock Absorbers on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Rear 2.0 reservoir shock, part number CSR-6525
  • Collapsed length of 19.15, with the unit to be confirmed before ordering.
  • Covers 2011–2018 Silverado and Sierra trucks in the HD range.
  • Bushing mounts, required hardware included

Description

Overview

The California Super Trucks CSR-6525 is a rear 2.0 reservoir shock absorber for 2011–2018 Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD trucks. It is gas charged and has a collapsed length of 19.15, with the unit to be confirmed before ordering.

This is the rear position of the CST reservoir shock series for these trucks. The printed lift range is 10 – 9.5 in., which is also unclear.

Key features

  • Rear-position 2.0 reservoir design
  • Gas charged
  • Collapsed length of 19.15 listed
  • Bushing mounts rather than heim joints

Measuring before you buy

Rear shocks on a heavy-duty truck control axle movement under load, so their length matters. Collapsed length is measured from eye center to eye center with the shock fully compressed, and the measurement should be taken at the same mounting points on the old unit. Compare the old shock with the new one in the same condition before ordering, and note the mounting style at both ends.

Worn rear shocks often leak oil down the body, feel soft or bouncy at the rear, and leave the tires cupped in a repeating pattern. Check the bushings and mounting hardware along with the shock itself, since a worn bushing can make a new shock feel loose. Rear springs, sway bar links and shock mounts are often inspected at the same time.

If the truck carries extra weight in the bed or pulls a trailer, the rear end works harder, and replacing both sides together keeps the ride even. Clean the mounting surfaces before reinstalling and check fastener tightness after the first few drives.

Specifications

Brand California Super Trucks
Part number CSR-6525
UPC 70000635820
Position Rear
Type 2.0 reservoir shock
Hydraulic / gas charged Gas charged
Collapsed length 19.15 (unit not stated)
Lift range (as printed) 10 – 9.5 in.
Mounting Bushings

Vehicle fitment

The list names the same four HD truck lines from 2011 through 2018: Silverado 2500 HD and 3500 HD and Sierra 2500 HD and 3500 HD.

It fits Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD trucks from 2011 through 2018.

Installation notes

Measure the existing rear shock in its collapsed state before ordering, and confirm the unit matches the 19.15 figure.

What’s included

Required hardware is included with the shock.

SKU: CSTCSR-6525 Category:

Specification

Shipping weight 10.00 lbs
Package dimensions 20.00 × 20.00 × 15.00 in
brands

Fitment

VehicleYearsTrims
Chevrolet Silverado 2500 HD2011–2018High Country, LT, LTZ, WT
Chevrolet Silverado 3500 HD2011–2018High Country, LT, LTZ, WT
GMC Sierra 2500 HD2011–2018Base, Denali, SLE, SLT, WT
GMC Sierra 3500 HD2011–2018Base, Denali, SLE, SLT, WT

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Is the CSR-6525 a front or rear shock?

Rear. It is a rear-position 2.0 reservoir shock, gas charged, with bushing mounts and direct fit for 2011–2018 Silverado and Sierra HD trucks.

What does the 19.15 collapsed length mean?

The 19.15 figure is the collapsed length of the shock, and its unit should be confirmed. Measure the existing rear shock in its collapsed state and compare it before installing.

Does the CSR-6525 mount at the rear of the truck?

Yes. Its position is rear, and it is designed for Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD trucks from 2011 to 2018. Confirm your year, model and trim before ordering.

How do I tell if a rear shock needs replacing?

Look for oil on the shock body, a bouncy or floating rear end after bumps, and uneven tire wear. Test the shock by pushing down on the rear bumper and checking whether it rebounds once and settles. Replace it if it keeps bouncing.
