Bushwacker Ford Bronco Cut-Out Rear Fender Flares (Paintable) – 20002-07

Bushwacker

Shop Ford Bronco Fender Flares on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Cut-Out Style rear fender flares for the Ford Bronco, pair of rear flares
  • 1.5 inches of width and tire coverage
  • Sheet metal removal maximizes wheel articulation
  • 100% UV protected Dura-Flex 2000 TPO, OEM matte black
  • Fits 1966–1977 Ford Bronco and 1975–1977 Ford Bronco Sport

Description

Overview

The Bushwacker Cut-Out Style rear fender flare pair, part 20002-07, is made for the Ford Bronco. This Cut-Out design is shaped around the Bronco to open up off-road wheel travel while keeping tire coverage. The pair adds 1.5 inches of width and tire coverage at the rear and fits the 1966 to 1977 Ford Bronco and the 1975 to 1977 Bronco Sport.

Full articulation and coverage for oversized tires depend on cutting away the body sheet metal on this flare. The design gives a smoother appearance and greater strength, and the pair is made from thick, warp-proof Dura-Flex 2000 TPO. UV protection keeps the finish from chalking, and the matte black finish can be left as is or custom painted.

Key features

  • Individually designed for the Ford Bronco
  • 1.5 inches of width and tire coverage at the rear
  • Sheet metal removal maximizes wheel articulation
  • Stainless steel hardware for an easier bolt-on installation
  • 100% UV protected Dura-Flex 2000 TPO that guards against chalking
  • OEM matte black finish that can be custom painted

Rear articulation and tire rub

The rear tire moves up into the opening during suspension compression, so rear cut-out flares should be checked at full compression as well as at ride height. Rubbing typically starts at the flare’s rear edge or at the lower corner nearest the wheel. Lift height, tire width and wheel offset all change the tire’s position, so test with the tires you plan to run.

Rear flares also protect the body from thrown rocks and mud. Clean out the gap between the flare and body regularly, since debris trapped there can scratch paint and hold moisture against the metal. Check welds and body-side fasteners after each season of off-road use.

  • Check clearance at full compression
  • Clear debris from the gap behind the flare
  • Inspect body-side fasteners after off-road use

Specifications

Brand Bushwacker
Part number 20002-07
UPC 90689100092
Position Rear
Quantity Pair
Width and coverage 1.5 inches
Material Dura-Flex 2000 TPO
Finish OEM matte black, paintable
Front pair part number 20001-07
Extra large rear pair part number 20005-07

Vehicle fitment

It fits the 1966 to 1977 Ford Bronco, including the Base, Custom, Northland, Ranger, Roadster and Wagon models in those years, and the 1975 to 1977 Bronco Sport.

The list covers the first-generation Bronco years only, so the 1992 to 1996 Bronco and later models are not included. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

The rear pair requires cutting body sheet metal, so it is not a bolt-on-only install. Follow the Bronco installation guide before cutting, and check the rear clearance at full suspension travel once the pair is on.

What’s included

Two rear Cut-Out flares. The front pair is part 20001-07, and the extra large Cut-Out rear pair is part 20005-07.

SKU: B/W20002-07 Category:

Specification

Shipping weight 6.00 lbs
Package dimensions 45.00 × 20.00 × 7.00 in
brands

Fitment

VehicleYearsTrims
Ford Bronco1966–1977Base, Custom, Northland, Ranger, Roadster, Wagon
Ford Bronco Sport1975–1977All

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Is this a rear pair or a front pair?

This is a rear pair. The front pair is part 20001-07, and the extra large Cut-Out rear pair is part 20005-07.

Does the rear pair need cutting?

Yes. Bushwacker says Cut-Out flares require cutting body sheet metal to achieve maximum articulation and tire coverage, so follow the Bronco installation guide before starting.

Will this fit a 1994 Bronco?

This pair fits the 1966 to 1977 Ford Bronco and the 1975 to 1977 Bronco Sport. A 1994 Bronco is outside those years, so it is not a match for this pair.

Can I run wider rear tires with these flares?

Possibly, but it depends on wheel offset, tire width and how the flare sits on the body. Test-fit the wider tire at full compression and on a hard turn before driving. If the tire contacts the flare or body, reduce the width, change the offset or adjust suspension height.
