ARB AR32 V2 Intensity LED Spot Driving Light – AR32SV2

ARB 4x4 Accessories

Shop ARB 4X4 Accessories Driving Lights on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • ARB AR32 V2 Intensity LED spot driving light, single unit, 165 watts
  • Universal fit; round, clear lens with a 6 degree spot beam
  • Effective output 7450 lumens; color temperature 5700 K
  • Submersible to 10 ft; amp draw 11.5 amps; surface mounting

Description

Overview

The ARB AR32 V2 Intensity LED spot driving light is a round, clear-lens LED driving light with a 6 degree spot beam, rated at 165 watts. It is sold as a single light and is universal fit. It is the spot version of the Intensity V2 range, engineered in Australia and made in the United States.

LEDs are an alternative to HID lights because they do not need time to warm up. The Intensity spot configuration uses HyperSpot optics to focus the beam, and the light produces a color close to natural sunlight at 5700 K. Effective output is 7450 lumens, with a rated lumen figure of 20000.

The Intensity range is vibration tested to military specifications and suits long periods on corrugated roads. Pairing the spot with a flood light gives long-range and shoulder-to-shoulder visibility.

Key features

  • LED light source with a listed 165 watt rating
  • 6 degree horizontal spot beam with HyperSpot optics
  • Round housing with a clear lens
  • Polycarbonate lens, which ARB describes as virtually indestructible
  • Submersible to 10 ft and compliant for radio interference suppression
  • Vibration tested to military specifications.
  • Intensity V2 chassis with updated LED technology

Choosing spot or flood

Spot and flood patterns do different jobs, so the choice depends on where the light will be used. A spot pattern throws light far down the trail, which helps with long sightlines on open tracks. A flood spreads light wide across the near ground, which helps at walking pace and on tight turns.

Many drivers pair a spot light with a flood light so each covers a different distance. Mounting height and angle affect the result more than the light itself, so aim each unit before using it at speed. Surface mounts sit closer to the body and are easier to reach for cleaning.

Mounting should keep the lens clear of mud and brush, and the bracket should be solid enough to hold the light through rough terrain. Vibration is a constant factor off road, so check fasteners and brackets after each trip. Keep the wiring routed away from hot or moving parts.

  • Aim the spot beam ahead of the vehicle
  • Keep the lens free of mud and brush
  • Check mounting bolts after rough trips
  • Route wiring away from heat and moving parts

Specifications

Brand ARB 4×4 Accessories
Part number ARBAR32SV2
Light series Intensity V2
Type Driving light, spot beam pattern
Bulb type LED
Light shape Round
Lens color Clear
Watts 165 watts
Effective lumens 7450 lumens
Listed lumens 20000 lumens
Color temperature 5700 K
Horizontal beam angle 6 degrees
Amp draw 11.5 amps
Mounting location Surface
Sold as Single
Submersion depth 10 ft
Fitment Universal fit

Vehicle fitment

This light is universal fit, so it is not sized for a specific make, model or year. Surface mounting means the mounting location on your vehicle must be able to take a surface-mounted light.

Installation notes

With an amp draw of 11.5 amps, wire the light through a fused relay rather than running it from a switch alone. Local rules on driving lights vary, so check them before fitting lights that will be used on public roads.

What’s included

The package is a single light, with a surface mounting location.

Not included: a wiring harness, switch, relay or mounting bracket.

Questions & Answers

Is the ARB AR32 V2 Intensity light universal fit?

Yes. It is universal fit, so it is not built for a specific vehicle. Check that the surface mounting location on your vehicle can take the light before ordering.

Is this light LED or HID?

It is LED. ARB says LED lights do not need time to warm up, unlike HID lights, and that the broad field of light helps on corrugated roads.

How much current does the AR32 V2 draw?

The listed amp draw is 11.5 amps, and the light is rated at 165 watts. Wire it through a fused relay, and confirm local rules for driving lights before using it on public roads.

How should the lens be cleaned and inspected?

Wash the lens with mild soap, water and a soft cloth, and avoid abrasive pads that can scratch polycarbonate. Inspect the seal and housing after rough trails for cracks or moisture. Reseal the housing if water gets in.

Should aim be checked after mounting?

Yes. Aim the light so the spot beam sits ahead of the vehicle at a height that suits the terrain, and recheck it after the mount has been loosened or the vehicle has been driven on rough roads.
