Warrior Front Wider Tube Fender Flares (Diamond Plate) – 7315

Warrior

Shop Jeep Wrangler JK Fender Flares on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front tube fender flares, 12.5 inches wide, for 2007–2017 Jeep Wrangler JK
  • 1.5-inch steel tubing with a diamond plate top
  • No drilling required; supplied as a pair
  • Optional LED side marker light available separately

Description

Overview

The Warrior Front Wider Tube Fender Flares, part number 7315, are a pair of front flares in diamond plate for the 2007–2017 Jeep Wrangler JK. They are also sold as W/I7315, measure 12.5 inches wide and replace the original front flares, mounting into the existing fender wells with minimal or no drilling.

The flares are built on 1.5-inch steel tubing that matches Warrior’s Tube Doors. The outer mounting and frame have a black powder-coated finish, and the top plate comes in polished diamond plate, black powder-coated diamond plate or textured black steel.

An uncoated bare steel top is available for owners who want to paint-match the flare. An optional LED side marker light can be built into the leading edge of the front flare, and it comes with a wiring harness for easy installation. Light kits are not included.

Key features

  • 12.5 inches wide, the wider front tube design
  • 1.5-inch steel tubing frame
  • Top plate in polished diamond plate, black powder-coated diamond plate or textured black steel
  • Bare steel top option for paint matching
  • Designed to mount with minimal or no drilling
  • Optional LED side marker light with wiring harness

Front flare considerations

A wider front flare changes the space around the tire and the front fender edge, so steering movement and tire clearance should be checked after installation. Turn the wheels fully in both directions and watch for contact with the flare, the fender liner and the bumper. Diamond plate and steel tops are sturdy, but the edges still need to clear the tire at full lock.

Choosing the top plate comes down to appearance and upkeep. Polished diamond plate shows more wear, while a black powder-coated top hides small scratches. A bare steel top can be painted to match the body, so the surface should be cleaned and primed before the color coat goes on.

  • Test steering at full lock
  • Check clearance to the bumper and liner
  • Prime bare steel before painting

Specifications

Brand Warrior
Part number 7315 (also sold as W/I7315)
UPC 634146731506
Position Front
Quantity Pair
Width/coverage 12.5 inches
Frame 1.5-inch steel tubing, black powder-coated outer frame
Top plate Polished diamond plate, black powder-coated diamond plate or textured black steel
Fitment type Direct fit; minimal or no drilling

Vehicle fitment

It fits the 2007–2017 Jeep Wrangler JK, including the 70th Anniversary, 75th Anniversary, Rubicon, Sahara, Sport, Sport S, X and Unlimited trims.

Wrangler generations outside the JK years, including the TJ, LJ and JL, are not covered. Confirm fit for your vehicle’s year, model and trim before ordering.

Installation notes

The optional LED side marker light mounts in the leading edge of the front flare and comes with its own wiring harness. The light kit is a separate item, so plan for it if you want the marker lights.

What’s included

A pair of front tube fender flares.

Not included: LED side marker light kits, which are a separate item.

SKU: W/I7315 Category:

Specification

Shipping weight 51.00 lbs
Package dimensions 46.00 × 20.00 × 12.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (JK)2007–201770th Anniversary, 75th Anniversary, Rubicon, Sahara, Sport, Sport S, Unlimited 70th Anniversary, Unlimited 75th Anniversary, Unlimited Rubicon, Unlimited Sahara, Unlimited Sport, Unlimited Sport S, Unlimited X, X

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Are the Warrior 7315 flares a pair?

Yes. The set is a pair of front flares, each 12.5 inches wide, with a steel tube frame and a diamond plate top plate that can be painted or left bare.

Do the flares need drilling?

Warrior says they mount into the existing fender wells with minimal or no drilling. The optional LED side marker light comes with its own wiring harness.

Is the LED side marker light included?

No. The LED light is an optional add-on for the leading edge of the front flare, and light kits are not included with the pair.

Does a wider front flare affect steering?

It can, if the tire or flare edge reaches the bumper, liner or fender at full lock. Turn the wheels in both directions after installation and check for contact, then adjust the setup if rubbing shows.

How should a bare steel top be protected?

Clean and prime bare steel before painting, then apply a matching color coat. Check the edges for early rust after wet conditions and touch up any chips promptly to keep the surface protected.
