Pro Comp 1.5 Inch Front Leveling Lift Kit – 55415

Pro Comp Suspension

Shop on Amazon

Compare current versions and compatible options on Amazon, then check out with your Amazon account.

Slickrock 4X4 is a participant in the Amazon Associates Program. As an Amazon Associate we earn from qualifying purchases.

  • Front leveling kit that raises the front 1.5 inches with coil spring spacers
  • Rear coil spring spacers included; no shocks in the kit
  • Fits 15-inch or larger wheels, 7 to 8 inch wide, up to 32×11.50 tires
  • Fits 2004–2005 Jeep Wrangler Unlimited (LJ) and 1997–2006 Wrangler TJ; part number 55415

Description

Overview

The Pro Comp 55415 is a 1.5-inch front leveling kit that uses coil spring spacers in the front and the rear. It fits the 2004–2005 Jeep Wrangler Unlimited (LJ) and the 1997–2006 Jeep Wrangler (TJ) in the Rubicon, SE, Sahara, Sport and X trims. The front lift is 1.5 inches, and the kit is sold without shocks.

The kit is designed for wheels 15 inches and up, with a width of 7 to 8 inches and a backspace of 3.25 to 4.5 inches. The maximum tire size is 32×11.50.

Leveling the front with spacers changes the height and the suspension geometry of the Jeep. An alignment and a check of the driveline angles are important after installation.

Key features

  • 1.5-inch front leveling with coil spring spacers
  • Coil spring spacers at the rear as well
  • No shocks included
  • Wheels 15 inches or larger, 7 to 8 inch width
  • Backspace range of 3.25 to 4.5 inches
  • Maximum tire size 32×11.50

Before you level

A front leveling kit is usually the first step for a Jeep that sits low in front, but it changes more than the nose height. The front geometry shifts, and the steering and braking loads move a little. Plan to check the steering components, brake hoses and the bump stops once the spacers are in, since the old positions no longer apply.

The shocks are the part most often overlooked. Because the kit does not include shocks, measure the existing shock length against the new ride height and look for leaks or worn bushings. Tire clearance also deserves a look at full steering lock and on full suspension compression, especially with the wider tires that many Wranglers run.

  • Check shock length and mounting before driving
  • Inspect the bump stops for proper contact
  • Test steering lock for tire rub
  • Recheck the alignment after the first few drives

Specifications

Brand Pro Comp Suspension
Part number 55415
UPC 614901111866
Front lift 1.5 inches with coil spring spacers
Rear lift Coil spring spacers
Shocks Not included
Wheel size 15 inch or larger
Wheel width 7 to 8 inch
Backspace 3.25 to 4.5 inch
Maximum tire size 32×11.50
Fitment type Direct fit

Vehicle fitment

It is a direct fit for the 2004–2005 Jeep Wrangler (LJ) Unlimited and for the 1997–2006 Jeep Wrangler (TJ) in the Rubicon, SE, Sahara, Sport and X trims.

The list does not cover the 2007–2018 JK or the 2018–2022 JL. Confirm your vehicle’s year, model and trim before ordering.

Installation notes

After the spacers go in, have the front alignment checked and measure the driveline angles, because the leveling changes the geometry of the suspension. Check the wheel and tire fit against the listed backspace and width ranges.

What’s included

The front and rear coil spring spacers for the leveling kit.

Not included: shocks, which the kit does not include.

SKU: EXP55415 Category:

Specification

Shipping weight 9.00 lbs
Package dimensions 12.00 × 10.00 × 6.00 in
brands

Fitment

VehicleYearsTrims
Jeep Wrangler (LJ)2004–2005Unlimited
Jeep Wrangler (TJ)1997–2006Rubicon, SE, Sahara, Sport, X

Use “Select your vehicle” at the top of the page to check this part against your vehicle.

Questions & Answers

Does the 55415 leveling kit fit a Jeep TJ or LJ?

Yes. It fits the 2004–2005 Jeep Wrangler Unlimited (LJ) and the 1997–2006 Jeep Wrangler (TJ) in the Rubicon, SE, Sahara, Sport and X trims.

How much does the kit lift the front?

The kit is a 1.5-inch front leveling kit that uses coil spring spacers. The kit does not include shocks, so check the shock length before you install it.

What wheels and tires does it suit?

Pro Comp lists wheels 15 inches or larger, 7 to 8 inches wide, with a backspace of 3.25 to 4.5 inches. The maximum tire size is 32x11.50.

Does leveling require an alignment?

Leveling changes the suspension geometry, so an alignment and a driveline angle check are important after the spacers are installed.

Does a leveling kit affect ride quality?

Yes. A change in spring height and rate can firm up or shift the ride. Check the shocks and bump stops after installation, since the ride may feel different until the suspension settles.

What should I check on the steering after leveling?

Check tie rod ends, the drag link and the steering stabilizer for play. Changed suspension angles can load these parts more, so inspect them while the front is raised and before the alignment.
