Overview
The Oracle Lighting LED Fog Light Halo Kit (White), part number 1177-001, is a halo kit for the fog lights of the 2007-2018 Jeep Wrangler JK, in both 2-door and 4-door models. The kit uses two SMD halos with pre-installed 3M adhesive tape and two LED drivers.
The halos are bright and draw less power than older halo types. The ColorSHIFT option gives RGB control through 5050 tri-node LEDs, so the color can be changed. Colors other than white and amber are not intended for on-road use, so check your state and local rules before choosing a color. The SMD halos sit on a CAD designed circuit board that mounts to the light housing with the 3M backing, and a controller lets the owner change the halo.
White and amber are the street legal colors for these halos. Verify the state and local driving laws before installing any color.
Key features
- Two SMD halos with pre-installed 3M adhesive tape
- Two LED drivers
- Vehicle specific wiring
- Bright output with less power consumption
- Customized look for the fog lights
- 1 year warranty
Color and driving rules
Color choice affects more than looks. Any color outside white and amber is meant for off-road or show use, so a halo set to another color should be switched back before the vehicle is driven on public roads. Keep the controller where it can be reached easily so the color can be changed without taking the lights apart again.
The halos mount with their pre-installed tape, so clean the housing and dry it fully before pressing them in place. Let the tape cure before the lights are reassembled, and route the drivers away from the bumper and heat sources. Recheck the connections after the first few drives, since vibration can loosen a plug.
- Keep the color set to white or amber for street use
- Clean and dry the housing before applying the tape
- Route drivers away from heat and the bumper
- Recheck plugs after the first few drives
Specifications
| Brand | Oracle Lighting |
|---|---|
| Part number | 1177-001 |
| Halo color | White |
| Included | Two halos, two LED drivers, vehicle specific wiring |
| Installation | Fog light disassembly required |
| Warranty | 1 year |
Vehicle fitment
It is a direct fit for the 2007-2018 Jeep Wrangler (JK) in the 70th Anniversary, 75th Anniversary, Rubicon, Sahara, Sport, Sport S and X trims, in 2-door and Unlimited 4-door versions.
It does not cover the JL generation or other Wranglers. Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Fog light disassembly is required before the halos are fitted. The halos attach with the pre-installed 3M tape, so plan time for taking the fog lights apart and reassembling them. The two LED drivers are separate units, so choose a mounting spot for them that keeps the wiring clear of the bumper. The vehicle specific wiring connects to the factory fog light plug as the included instructions describe.
What’s included
Two ORACLE halos, two ORACLE LED drivers and the vehicle specific wiring.
