Overview
The N-Fab RKR Rock Rails in black, part D104RKRMC, are rock rails for Ram 2500 and 3500 Mega Cab models. They fit 2009-2010 and 2011-2018 Ram 2500 and 3500 trucks in the trims named for each range.
The rails use a non-modular, dual-bar welded assembly with a 1.75 inch main tube diameter. They are shaped to fit tightly along the body. The standard color is textured black powder coating, applied with N-FAB’s 3-stage powder coating process.
Key features
- Direct bolt-on using pre-existing factory mounts
- Non-modular, dual-bar welded assembly
- 1.75 inch main tube diameter
- Textured black powder coating with a 3-stage process
- Shaped to fit tightly along the body
Things to check
Mega Cab trucks have a longer cab, so the rock rails sit along a body length that sees more contact on rough approaches and tight trails. Check that the rails sit evenly under both doors and clear the wheel wells before you tighten the final fasteners.
The factory mounts carry the load when a rail takes a hit. Before a trip, look at the mount bolts, the mount brackets on the frame, and the welds where the two bars join. Loose fasteners are the most common issue, so re-torque them after the first few outings.
If you add detachable steps later, plan the mounting points before buying. Fit the steps only after the rails are secure, and keep clearance for the door when it opens. Touch up any chipped black powder coat early, since exposed steel is where rust starts.
Specifications
| Brand | Nfab |
|---|---|
| Part number | D104RKRMC |
| Main tube diameter | 1.75 inch |
| Construction | Non-modular, dual-bar welded |
| Finish | Textured black powder coating, 3-stage process |
| Mounting | Direct bolt-on using pre-existing factory mounts |
| Fitment | Direct fit |
| Detachable steps | Part JPTS32, sold separately |
| Warranty | 5-year finish, lifetime workmanship |
Vehicle fitment
The manufacturer fitment list covers 2009-2010 Dodge Ram 2500 (Laramie, SLT, SXT, TRX) and 3500 (Laramie, SLT, SXT), and 2011-2018 Ram 2500 (Big Horn, Laramie, Laramie Limited, Laramie Longhorn, Limited, Lone Star, Outdoorsman, SLT) and 3500 (Big Horn, Laramie, Laramie Limited, Laramie Longhorn, Limited, Lone Star, SLT).
Ram 1500 models and model years after 2018 are not covered. Confirm fit for your year, model and trim before ordering.
Installation notes
These rails bolt on to the factory mounts. Confirm the Mega Cab body style before starting the install.
What’s included
The rails are supplied without the detachable steps.
Not included: Detachable steps, part JPTS32, sold separately.
