Overview
The B&W Trailer Hitches Tow & Stow TS20049B is a black 2.5 inch receiver trailer hitch with a tri-ball combination, ball sizes 1-7/8, 2 and 2-5/16 inches. It is a stow-style hitch that stows under the vehicle when not in use, so the receiver stays clear when no trailer is attached.
The Tow & Stow design covers several ball sizes in one hitch, so a single unit can replace multiple ball mounts. It is rated for 14,500 lbs GTW and 1,450 lbs VTW. It has a two-step e-coat and powder-coat finish for corrosion protection inside and out, is made from high-yield tubing, and carries a Limited Lifetime Warranty.
Key features
- Tri-ball combination with 1-7/8, 2 and 2-5/16 inch ball sizes
- Height adjusts in 1 inch increments
- Locks into the receiver tube to help prevent theft
- Two-step e-coat and powder-coat finish for corrosion protection inside and out
- Manufactured from high-yield tubing
- Stows under the vehicle when not in use
- Limited Lifetime Warranty stated by the manufacturer
Using a stow-style hitch
A stow-style receiver hitch lets the tube stay out of the way for everyday driving, but the folding joint and locking pin need regular attention. Clean the tube and the stow mechanism after exposure to road salt or mud, and lubricate the pivot points with light grease so they fold without binding.
When choosing a tri-ball setup, match the ball diameter to the trailer coupler before towing rather than assuming a ball fits. Ball height changes with the drop and rise, so measure trailer level after each adjustment. Check the locking pin and ball nut before every trip, and replace worn hardware early because a loose ball is a serious hazard on the road.
- Check the locking pin before each trip
- Recheck the ball nut after the first tows
Specifications
| Brand | B&W Trailer Hitches |
|---|---|
| Part number | TS20049B |
| UPC | 843233003741 |
| Product type | Trailer hitch ball mount |
| Receiver size | 2.5 inches |
| Drop | 7 inches |
| Rise | 7.5 inches |
| Height adjustment | 1 inch increments |
| Ball size | 1-7/8 x 2 x 2-5/16 inches |
| Gross trailer weight (GTW) | 14,500 lbs |
| Vertical tongue weight (VTW) | 1,450 lbs |
| Finish | Black powder coat over e-coat, two-step finish |
| Warranty | Limited Lifetime Warranty |
Vehicle fitment
Vehicle fit is not confirmed for this hitch by year, make or model. It has a universal fit and a 2.5 inch by 2.5 inch rear receiver. Measure the receiver opening and rear clearance on your vehicle before ordering.
Confirm your vehicle’s year, model and trim before ordering.
What’s included
Hardware is not confirmed here, so compare the package contents with your installation before starting.
