Overview
The 9 Inch Panoramic Rearview Mirror in black, part number MOD9PRVM-BK, is a wide rearview mirror for off-road vehicles. It is universal fit and comes with the clamp adapter. It is the 9-inch model in Axia’s mirror line and shares its design with the 17-inch panoramic mirror.
The mirror gives a low-distortion view through a shatter resistant glass insert. It is convex only in the horizontal direction, so objects appear where they really are in relation to the vehicle.
Key features
- Low-distortion view through a shatter resistant glass insert
- Convex only in the horizontal direction
- Infinite adjustability
- Can be post mounted horizontally or vertically with a 3/8-16 thread post
- Can be clamp mounted horizontally or vertically with Axia’s patented modular rollcage mounting system.
- Adjustable mounting ball tension for demanding off-road use
- Clamp adapter included, so it can be used with any size clamp
Mounting options on a cage
A rearview mirror on an off-road cage has to resist the same vibration as the rest of the build. Post mounting into a welded nut or bung gives a fixed, low-profile position, while clamp mounting lets you place the mirror on the tube where it suits your seating position. Choose the method before drilling or welding anything, because it decides which parts you need.
Infinite adjustment and adjustable ball tension let you set the view once and hold it. Tighten the tension for rough terrain, and loosen it slightly if the mirror is hard to reposition by hand. Inspect the post threads and the nut or bung after hard runs, since worn threads can allow the mirror to shift.
- Post mount for a fixed position
- Clamp mount for flexible placement
- Check thread condition after hard runs
Specifications
| Brand | Axia Alloys |
|---|---|
| Part number | MOD9PRVM-BK |
| Width | 9-inch panoramic |
| Glass | Shatter resistant insert |
| Curvature | Convex in the horizontal direction only |
| Mount | 3/8-16 thread post, or clamp (with adapter) |
| Color | Black |
| Adjustment | Infinite, with adjustable mounting ball tension |
| Clamp adapter | Included; removable for post mounting |
Vehicle fitment
Fit depends on your roll cage and mounting spot, since the mirror mounts to a rollcage with a clamp or to a post with a 3/8-16 thread. Confirm fit for your vehicle’s year, model and trim before ordering.
Installation notes
The mounting ball tension is adjustable and can be tightened for demanding off-road use. The clamp adapter is supplied so any size clamp can be used, and it can be removed to post mount the mirror into a welded nut or bung on the cage with its 3/8-16 thread.
What’s included
The clamp adapter comes with the mirror, so have it ready before mounting.
