Overview
The Rhino-Rack Foxwing Awning Bracket Fit Kit, part RHO31102, lets you fit a Rhino-Rack Batwing awning to an ARB tray or a TJM tray. It is also known as the Batwing Tubular Rack Bracket Kit.
The bracket is designed for drivers who want the Batwing shade available on their tray or platform for trips. Rhino-Rack engineered the bracket to be easy to install on either tray type.
Key features
- Fits the Rhino-Rack Batwing awning
- Compatible with ARB and TJM trays
- Made with powder coated steel
- Corrosion resistant finish
- Engineered for easy installation
Tray types and awning mounting
Trays are not all the same, so the first step is confirming whether yours is an ARB or a TJM unit before buying any bracket. Measure the tray rails and any fittings you plan to use, and note how the awning will sit relative to the tray so it clears the cab and any rack equipment.
Powder coated steel resists corrosion while the finish stays intact, but chips can let rust start at the edges. Look over the bracket and fixings every few months and after rough tracks. Tighten any bolts that have loosened, and touch up chips before rust spreads. Remove the awning before major maintenance.
- Confirm tray type before purchase
- Check fixings after rough tracks
- Touch up chips in the finish promptly
Specifications
| Brand | Rhino-Rack USA |
|---|---|
| Part number | RHO31102 |
| Product type | Awning bracket fit kit |
| Material | Powder coated steel |
| Compatible awning | Rhino-Rack Batwing awning |
| Compatible trays | ARB tray, TJM tray |
Vehicle fitment
It is matched to the tray type, so confirm whether your tray is an ARB or a TJM unit before choosing it.
Confirm your vehicle’s year, model and trim before ordering.
Installation notes
Identify your tray first, since the kit is named for ARB and TJM trays. The bracket is what carries the Batwing Shade, so the awning must be fitted to the bracket once it is in place.
What’s included
Check the package contents against your installation before starting.
Not included: the Batwing awning and the ARB or TJM tray the bracket fits to.
