Overview
The Smittybilt Bowless Combo Top with Tinted Windows in Black Diamond, part 9973235, is a soft top that works as a primary weatherproof top. When the weather clears, the side and rear windows zip out so the cab is open again. Confirm fit for your vehicle’s year, model and trim before ordering.
The top does not need factory bow hardware. It requires a windshield header, the factory door surrounds and the factory tailgate bar. The windshield header is sold separately and will not work with the factory windshield channel, so plan for the header before ordering. Upper door skins and hardware are not included.
Smittybilt built it from marine grade durable vinyl coated fabric in an OEM diamond style that resists fading and stretching. The seams are heat-sealed, and the wick stop thread seals the stitch holes. Internal storage compartments hold the removable side curtains and the MOLLE attachments add room for gear.
Because the windshield header is sold separately, plan for it at the same time as the top so the install goes as planned.
Key features
- Functions as a primary top and converts to an extended top
- Marine grade durable vinyl coated fabric in an OEM diamond style
- Heat-sealed seams and wick stop thread that seals stitch holes
- DOT tinted glass, 30 ml
- Internal storage compartments and MOLLE attachments
- Self-correcting zippers
- Resists fading and stretching
Planning the header
A soft top that depends on a windshield header needs the header planned into the install, not added at the end. Choose the header first, then confirm that the door surrounds and tailgate bar are in place. Soft tops stretch slightly as they settle, so expect to adjust the fit after the first few weeks of use.
Zip-out windows and side curtains wear faster when they are folded or stored damp. Air the top out after rain, keep zippers clean and lightly lubricated, and store removed panels flat. Watch for cracked seams, sagging around the header or torn stitching, which usually means the top needs attention before the next trip.
- Keep zippers clean and dry
- Air out the top after rain
- Inspect seams for cracks each season
Specifications
| Brand | Smittybilt |
|---|---|
| Part number | 9973235 |
| UPC | 631410123043 |
| Color | Black Diamond |
| Window type | Tinted, 30 ml DOT glass |
| Doors included | No |
| Hardware included | No |
Vehicle fitment
Match your year, model and trim before placing the order.
Installation notes
The factory door surrounds and factory tailgate bar must be in place, and a windshield header is needed in addition. The windshield channel is sold separately.
What’s included
The soft top with its tinted side and rear windows, and its internal storage compartments.
Not included: Upper door skins, door hardware and the windshield header.
